Perfect timing as so often happens as this is one item I’m dealing with right now. At 40ft and barely 310 sqft of mainsail simply cannot justify a hydraulic vang, as much as they do look a very cool solution.
After sorting through quite a few of the mechanical vang options, I’m rather attracted to this elegantly simple device:
https://www.boomkicker.com/
Any thoughts or experiences here?
Hi Philip,
one of the boats that I mention below was a First 34.7 and she was equipped with a kicker of the type you link to. I didn’t notice any difference in performance to the mechanical vangs on the other boats, meaning it didn’t really hold the boom up when the sail was down. Probably ok, when combined with a topping lift.
Thanks. I’ve got the opportunity to add a boom gallows quite readily, and in light of what you say, it would seem a good idea.
Hi Philip,
Definitely a good idea if it works on your boat.
Hi Philip,
Given that you are right at the top of the size range for the boomkicker, if it were me I would go with a more substantial mechanical vang probably from Seldén. It’s seldom a good idea to fit a piece of gear that only barely matches your boat size.
Have a look at Garhauer gear. Its very strong, simply designed and the costs won’t break the bank. I bough 2 last summer for my ketch and the 2 vangs and new main and mizzen sheet blocks only cost me $1300 delivered
Garhauer are my first choice of mechanical vangs, and from the helpful feedback here I’d probably be better off going with them. At least I only need one. 🙂
I have a boomkicker on my Ranger 29 with no topping lift. It’s nice as a piece of sail trim gear. Easy to install, reliable to use. But it’s a nightmare when you try to flake your sail and it keeps wiggling and sinking when you put your weight on it. And it’s almost impossible to secure your boom in a blow. I tend to tie the boom off to the side on the toe rail and then tighten the mainsheet, but it’s still a bit sloppy.
Hi Courtney,
As I wrote in the post, you either need to have a topping lift or a boom gallows. I have a short post coming on how to make the latter less of a pain in the neck.
Hi John,
I JUST LOVE MY TOPPING LIFT ! Wouldn’t want to sail without it. I often think of you when I douse the main, sheet to one side of the traveller car, vang tackle to the other, both tightened against the TL, which locks the boom rocksteady in position, enabling me to safely secure and fold the sail. Sometimes, smiling, I even mumble to myself about “John’s invention of the devil”.
Compare that to my experience on 4 race boats that I delivered over the last few years: Main is down, sheet “tightened” against the mechanical vang, even with a line to the toe rail to prevent the worst of boom movement it still is a real pain trying to fold and secure the sail on a boom that gives me a spongy feeling and still swings from side to side because the vang is everything but rigid. Was I out of luck and all these vangs were not strong enough ? Could be, as 3 of the 4 boats were of the same type (Archambault 35). You are of course right when it comes to twist control, nothing better than a rigid vang, but no topping lift ? Never had any problem with chafe or noise, just taking up the slack fixes that and it always provides a spare main halyard, so why is it an invention of the devil ?
Hi Hans,
Yes, good point that if you don’t have a gallows you really need a topping lift. In fact I say exactly that in the above post. As to why I hate them, I will expand more in the post I’m doing on a hack to make them less hated…if that made any sense.
Hi I have a Profurl in-boom furling system on my 50ft steel cutter. It comes with a ‘push-up’ vang that only supports the boom to the correct height for furling/reefing but allows no further adjustments whilst sailing!!!
I actually use the traveller in reverse to allow the main sheet a better angle to pull down the boom and reduce twist.
Any ideas on a better vang that would also ensure accurate furling?
Hi Kim,
Yes, that’s one of the many things I don’t like about in boom furling. That said, I think you could come up with a system that would work with a good powerful hydraulic vang from Navtec or Seldén. Going that way the challenge is going to be making sure that you have a way to get a repeatable setting for furling. I’m thinking a Spectra strop parallel to the vang (that could be slackened when sailing and then tensioned to a mark) that the vang can push against might solve the problem.
I would definitely fix this since, if I read you right, you currently have no way to dump the vang from the furling position in a big gust.
Hi Kim,
We run Leisurefurl in boom furling on our 47 foot Beneteau 473 sloop with an alloy mast. This is marketed and branded Forespar in the USA. You can see an interesting comparison by a US based rigging company here where the Profurl limitation you discuss is mentioned as a benefit, haha:
https://theriggingco.com/2016/12/26/which-boom-furler-is-the-best/
When sold in NZ the Leisurefurl boom comes with a recommended, solid, but very simple Forespar rigid vang. This vang has numerous adjusting pin positions to set the right boom angle you want. With such a vang, you could set the pin for a lifted boom (like we do) and mark the vang line at your clutch, and winch down to the mark for a horizontal boom, day or night.
On our boat we find the sail actually stows better with a slightly lifted boom (above horizontal) and so just let go the vang before reefing or furling. Works for us day or night, offshore, upwind and even downwind (with a centred boom and lots of halyard tension), in any wind. Since learning about the slightly elevated boom height (2016), we have never had the sail bunch up, and we never need anyone checking at the mast.
What you describe Kim seems to me a flaw in the Profurl design implementation, not a weakness of in-boom reefing per se. We have Profurl reefing for our jib which works fine, so it seems a strange sailing performance oversight for a French owned company to make?
If you reply with an email I can send you some photos of our set-up, if that would help.
Br. Rob
Hi that would be great –
The furling and reefing works really well even in boisterous conditions, it’s just the leach twit issue I’d like to address. Profurl wrote back to me and said that was it so ‘tough’.
Hi Bob,
Are you saying you must centre the boom to reef even if you are say broad reaching or running? If so that scares the hell out of me since over-trimming the main in a building breeze (or worse a squall) is a good way to have a spectacular wipe out.
Hi John,
Sorry for the confusion, let me clarify.
Up wind and reaching, recommended method is the jib is over-sheeted slightly, and the main sheet released until the main backwinds and the battens invert (so there is no flapping of sails) and the boat goes quiet and docile rather like being hove-to, but with more forward speed. This is the recommended way to reef under sail only (no engine).
Even with moderately aft raked spreaders like ours, there is a force pushing the sail forward going downwind, which wouldn’t be there if we had in-line spreaders and the boom was square. When we tried it, the sail would bunch up at the throat. So in 2018 we re-tied the clew further aft on the mandrill and lifted the rigid vang one hole higher, but can’t comment yet on whether it would work in anger, as we haven’t had offshore conditions. But I do know of cats using Leisurefurl booms with big aft spreaders that manage to reef downwind by keeping lots of halyard tension on as the sail is furled – but less than ideal mode and probably hard on the sail – so I wouldn’t fit in-boom furling on a cat.
We successfully experimented (offshore) with running square and bringing the main into the centre line (hence my comment above) using the mainsheet and topper, just as if you were about to gybe. And then keeping lots of halyard tension on, reefing. In big waves and wind we usually already have two reefs going to third reef, or third to forth. And once readied, actually taking each reef takes 5->10 seconds and the main can of course be released at any time, like during any normal gybe.
Having said that, if we were caught in a big squall with full sail up and needed two or three reefs quickly, we would come up to a reach or close-haul. Both methods have worked for us in over 30 knots just fine, though we always have someone on the helm reefing downwind. It is something to be aware of.
Br. Rob
Hi Rob,
Thanks for the clarification. I have to say that I still don’t like the requirement to pull the boom to centre line or round up to reef down wind. In fact that was the deal breaker for us when we looked at roller furling booms some years ago.
Hi Kim, John,
A further comment for those considering retro-fitting rigid vangs with in-boom furling – we completely love our setup and wouldn’t swap it for anything. But furling booms can be 30~50% heavier than similar sized conventional reefing booms, unless you pay big $ for a carbon shell and mandrill.
Our Leisurefurl boom uses a large, beautifully cast alloy gooseneck made to fit our mast section. But the Forespar rigid vang was attached using a much smaller casting than the one for the boom, and at the time we retro-fitted the boom I wondered, “why not use the same larger size attachment to spread the loads?” After all these loads would be in different directions, but surely equally big as at the gooseneck…?
Offshore in 2017 and in big waves, we could indeed see the vang attachment moving slightly against the holding screws and so we “nursed it” around the Pacific. I was kicking myself for stupidly not backing my instinct on this, and insisting on the larger one. After all compared with the cost of the boom and new full batten main, it was such a marginal cost item.
So when we re-rigged in 2018 and the mast was hauled, we changed to the same fitting we have at our gooseneck, and then put aluminium backing plates behind the new vang attachment (and gooseneck). From this whole experience, and not withstanding Jay’s comments, I respectfully suggest these extra steps should be standard (for all mast types) when retro-fitting a rigid vang on these heavier booms, and highly recommended for all other boom types, but perhaps when you next have the mast out (for going offshore). Don’t all booms load up the vang attachment equally, when splashed down to leeward, running in big waves?
Br. Rob
Hi Rob,
Good recommendation on vang mounting size. Not sure where you got the idea that Jay would not use a backer plate and up size the fitting. What he said was that he had not had to have custom fittings fabricated.
Anyway, no question that they should be massive. When we had our Hall mast built I specified that the vang fitting needed to designed to take a full mainsail crash jibe in 30 knots of wind—never done it. Judging from the amount of carbon build up (our goose necks are carbon) they heard me.
As to dragging the main in the water, the vangs for a non roller boom does not have an end stop close to the sailing position so if the line or hydrallics are dumped the boom rises far higher thereby clearing the water in all but the worst broaches, and even if it does touch the loads are lower since the sail is ragging.
The other point is that a slab reefed boat has rocker in the reef clews (each higher than the last) so by the time the third reef is in the boom is way up above the water.
Hi John,
Idea from this comment attributed to Jay “If you have a carbon fibre spar, be particularly careful that the loads are well distributed and the fittings properly attached—machine screws do not hold well in carbon fibre so an aluminum backer plate inside the mast and/or boom may be required.” The “may be” seemed to infer it wasn’t standard, and so by inference unnecessary in an alloy mast?
Anyway, for those boats that don’t get winter stored, taking the mast out to add backing plates is a major cost, my point being for the heavier booms it should be part of the standard install and budgeted for. Our attachment was just screwed on by the NZ rigger (no backing plates) until two years later. Much happier now I must say!
With the Forespar rigid vang, we have the same control as a conventional boom, but that doesn’t prevent a big roll to leeward under pressure, especially at night when you can’t see stuff coming. But really good point about the batten rocker – a downside of parallel battens. We fitted our boom gooseneck above where the old slab boom was that it replaced, for exactly this reason. But we don’t miss that sail area as we have a powerful roach (upside of lots of parallel battens).
Br. Rob
Hi Rob,
Actually it was me that added that to Jay’s comments based on the experience he and I had with the terrible mast GMT sold us.
And I agree that backer plates at the vang attachments should be standard on all masts and booms. However I can’t see that ever happening given that most sailors don’t go offshore or even put many hours on their boats, so there is just no market demand for that kind of up strengthening. Sadly true of so much gear that just won’t stand up once we go offshore.
Beware – Having used a Selden Vang on our 40 footer cruiser for about 10 years I decided to completely strip it down to check for any internal wear one winter, shock horror, the internal end of the male part had worn away which would have eventually led to the collapse of the whole unit and possibly injury also, given the loads that it could be under.
Other than that totally agree – lose the topping lift.
Hi James,
That’s disturbing indeed. Did you contact Selden about this?
No, though having told others of my findings it is probably quite a common problem.
The wear is caused as the Male /Female slide into one another, the plastic spacer /end of the male wears and then can rub aluminum to aluminum.
This is aptly timed; we are also thinking of fitting a proper vang as part of our winter update (it’s not extensive enough to be a “refit”) of Maverick V.
Re. Boomkicker rod-spring vangs. I have been finding good reports of their performance on 14’ to 37’ boats, but the largest model, K1500, is maxed out with about a 16 to 17 foot boom and a 260 to 280 sq.ft mainsail. Few boats over 37 or 38 feet LOA can use it.
We are also looking at Garhauer rigid vangs. Their reputation seems to be good, and the price is more manageable than a Selden or Forespar, but since nobody stocks them (they seem to be direct order only) it’s hard to assess the quality.
We have a massive boom gallows (nice) and a fixed topping lift with a 1:1 tackle at the boom end (awful for me, unusable for Katy). With smaller crew who can’t lift the boom themselves, I think relying on the vang instead of the topping lift will be much more manageable.
I have 2 Garhauer vangs (ketch) and they are better finished then the Forespar vangs I’ve seen. They are definitely heavier being made of mostly stainless steel. but they aren’t “stocked” because they are all custom made to your measurements.
When I ordered my traveller from Garhauer (a triple-block “beam” type to replace an old “pin” version Harken), I got a call from “Guido” at Garhauer asking if I wanted 1/4″ or 5/16″ mounting holes? As the hole centers were identical, and it was simple to access the area on our steel boat, I saw no downside to going bigger. But the times I’ve had a gear manufacturer call me up to get a clarification before finishing the item in question remains at “one”.
Hi Matt,
I like that the custom design, including mounting plates, for each boat.
Update after a few seasons with one: the Garhauer spring-loaded rigid vangs are of excellent quality, easy to use, effective, robust, and very good value for money. Their application-specific brackets (made using cardboard templates that you cut to fit your spars and then scan or mail in) are very sturdy. I’d happily spec them as OEM fitment on anything I design going forward.
Hi Matt,
Good to hear, I have long been a Gerhauer fan. They were the OEM for much of the J/109 hardware and made me new back and forestay chain plates, beautiful made at an incredibly reasonable cost.
Article refers to boom gallows. Followed the link, and searched AAC. I’m sorry I found mention of it but not a discussion of your set up. Did find a closeup picture but gallow to boom connection was hidden by canvass, is it just a ‘U’ shaped crutch? Is there a description of your gallows? Your fitting is detachable, so just stored somewhere when not in use? Picture? Thank you.
Hi Rick,
Did you scroll all the way down on the linked article? There are two photos, one with the boat sailing and one with the boom stowed.
That said, as you say the actual boom interface is obscured, but yes it’s just a simple U shape and the whole assembly is removed when sailing and stored in a cockpit locker. This works fine for us, but I have also seen boom crutches and gallows where the top part folds down.
There is also the option of making the gallows higher so that nothing needs removing but the trouble with that is that one loses a bit of sail area since the main must be cut with the clew quite a bit higher than horizontal (don’t forget rake) so that it always clears the gallows when sailing.
Thks. Yes I did scroll all the way down. On the arch there are 4 fittings, three of them are black on top. What is this for and why not all of them? On the two that are not in use it looks like something smaller diameter is on top. Are these plugs to stop water ingress? It looks like the fittings on the arch are open pipe, so the female end. If they are, was there a design reason not to put the male (closed) fitting on the arch and a female fitting on the removable crutch?
Hi Rick,
The boat came with that set up and it has worked well for 30 years so I have not given it a lot of thought, except as I already stated it might be cool (not vital) to have the crutch itself hinge down when sailing to save stowing it. That said, I have not given it much thought or done any design work.
The four small lengths of pipe welded to the top act as female sockets for the crutch. There are four so the crutch can be fitted either side, but we always use it to starboard, so the port ones have wood plus just to finish them.
I second the request for a run through on your boom gallows. I’ve used fold down crutches on big boats, and classic teak/bronze gallows with little dishes for the boom. But I’ve also been on boats that had the gallows too high so the boom was at risk of hitting it when you tacked. I’d love a mini post about your gallows design, the steps for using it, and pros/cons.
Hi Courtney,
I will think about it, but it will be a while since there is a lot ahead of it in our publishing schedule. And yes, it should not be too high. A boom that hits the gallows probably means that the designer forgot to allow for rake, as I said earlier. Simple answer is just to cut the main and move the clew up a bit.
Hello John,
Very useful and instructive topic, not frequently treated.
On our Hallberg Rassy 46 from 2003 we have a Navtec Vang, Works well.
By precaution I have on board a seal kit in case…
The Selden boom is strong for the 50 sqm sail I have noticed that the under boom bolts have a tendency to enlarge by corrosion the threads. We also managed to have a system to install a backing plate in the boom. Not so easy to install at 2m distance from the extremity.
Our topping lift is a 10mm dyneema so it can be used also as a spare mainsail halyard or also to hoist our Banner bay riding sail.
My question is about the automatic release valve I don’t see it, our panel both manages the vang and the Navtec backstay hydraulic piston. We have in mast hydraulic furling, are your 2000psi values transposable? We try to keep the boom around 87° for reefing the mainsail
Thank you.
Denis
Hi Denis,
The auto release valve is on the back side of the panel (I think) and must be adjusted by a trained Navtec maintenance shop (Jay did ours).
On transportability I wrote:
We came up with 2500 for the valve and 2000 for as a proxy for reefing from observation over the years.
I’m guessing the right numbers for you will be much lower.
As to the bolts enlarging from corrosion that’s almost certainly because they were not coated when installed. I like Tef-Gel others like Duralac, but sadly very few people use either and that includes a lot of “professional” riggers.
Beatrix (KP44) has a Hall Quickvang which has worked well over the years. But, I had issues with the vang bracket attachment fasteners being simply threaded into the boom and mast. I did have a failure, about 10 years after installation, on the vang-to-boom bracket.
The metal is very thin, subject to galvanic corrosion if not properly maintained, or over-torqued (by a previous owner of course). Maybe this is just a generic problem that comes from hanging hardware on a mast or boom with a cross-section that allows for barely three threads.
So I developed a simple method to insert threaded 12mm aluminium backing plates inside a boom or mast. Step-by-step instructions are available in the March 7, 2011 issue of Cruising World or from my website:
On my website
Cruising World Article
Jeff
s/v Beatrix
Tasmania
Hi Jeff,
That is just plain brilliant. Love it. I will link to it in a piece I’m writing.
Just curious, Jeff, did you go straight to aluminum backing plates or did you consider stainless steel pem nuts / swage nuts first? Pem nuts aren’t exactly easy to press in from the backside (although you can pull them into place by the threaded fastener). But they do give you a lot of thread engagement plus good load spreading on the thinner metal, and ensure that the thread contact is all stainless-to-stainless for easier removal/servicing later.
Hi Matt,
No. The aluminium backing plate is strong, easy to work, and is not a “dissimilar metal”. I got into this when a professionally installed Quickvang pulled out of the mast.
Awesome Jeff,
True ANZAC #8 fencing wire solution – love it.
Similar issue with my 9 year old but new-to-me boat’s Eurospars vang 3 years ago. Checking some bubbling on the lower slide showed it had completely corroded through about 15% of its circumference, though the massive spring was mainly surface rusting only. After sorting that I’ve now noticed that the boom attachment has a hairline crack which needs replacing before I dare put to sea again. My very experienced rigger (now a good personal friend!) tells me that failures at this point are often missed by cruisers as few tend to actually look there routinely. John’s article and warnings are indeed timely.
Hi Iain,
Yes, that is indeed a weak spot. In most installations the boom should be sleeved there to strengthen it. More coming.
Hello John,
Since my question was burried in my comment. I repost it separetly
:
My question is about the automatic release valve I don’t see it, our panel both like yours although SS manages the vang and the Navtec backstay hydraulic piston. We have in mast hydraulic furling, are your 2000psi values transposable? We try to keep the boom around 87° for reefing the mainsail
Thank you.
Denis
I would expect not. The correct pressure for your boat will depend on the piston diameter, the angle the vang makes with the boom, the gooseneck-to-vang distance, the length of the boom, the weight of the boom, and the area of the sail. It won’t scale in a clean/easy fashion from any other boat.
If you think you know your boat fairly well, you can try sailing her “conservatively” and then try sailing her “hot” and note the pressure you’re actually getting in both of those conditions. Then set the relief valve to somewhere between your “hot” reading and what the vang vendor provided as the default maximum. Then decide how much you trust other helmspeople and give them the “conservative” number plus or minus some margin that makes you happy.
Hi Matt,
Exsactly. And I should clarify that none of this changes the age old wisdom “the time to reef is when you first think about it”.
Interesting. I think I will offer a contrasting view from a multihull guy. In fact, I’ve never sailed a multihull with a vang at all, because a wide traveler can serve the same purpose.
a. Tangling on battens when hoisting. This is generally not a problem with sails that run a lot of roach, as do most multihull sails. Same with lazy jacks.
b. Breaking. I run the same strength topping lift as main halyard, so no, that does not happen. It gives me another spare halyard and a good safety line when climbing the mast.
c. Boom falling into cockpit. In fact, on many cats with hard tops, it’s not going to fall far at all, no more than a few inches or a foot.
d. Quick release. On a multihull, the ability to dump sail fast must not be compromised. Yes, you can still do this with a vang, but one less thing….
e. Space. often the mast vs hard top geometry would interfere with the vang. There is simply no clearance.
f. Chafe. I’ve worn out a good number of sails, but the topping lift was never the problem. I think perhaps the chafe guards for the cap shrouds protect against both.
I certainly see the value of rigid vangs, just not for every boat. A few multis have them, but it is a small minority, even among large cats.
Hi Drew,
The first draft of my article exempted multihulls but then I trashed it because I think that’s too simplistic. For example, many cruising cats and tris don’t have full width travellers (most?) and are too heavy with too much volume in the hulls to sail hot angles efficiently. So sure, some multihulls don’t need a vang, but many do. Dragonfly trimarans come to mind as a boat with no traveler and that means the crew must rig a tackle down to the leeward hull when reaching—way less elegant than a good vang: https://dragonfly.dk/dragonfly-28
And the probable reason you have not had topping lift or spreader chafe is simple one of time and sailing inshore out of swell. For example, do a downwind trans-Atlantic and even if you have chafe guards on the spreaders, there will be holes in the sail by the time Barbados comes up over the horizon, if the sail is allowed to touch pretty much anything, and if the topping lift has been slapping around all that way, the leach will be toast too—tip coming on how to fix that.
I would also not trust many of the hard tops I see on production multihulls to protect me and mine from the boom.
Bottom line offshore sailing requires a lot more attention to chafe details than inshore.
Yes… and no.
Regarding the need for a vang, yes, many multis probably could benefit. I have considered adding one more than once, but declined due to added complexity. When there is a need to stabilize the boom or pull it down, rigging a tackle for that purpose only when needed is trivially easy with a wide beam. I’m not above modifying boats–I do it all the time–but in this cases it is seems an arrogant view, considering that virtually all of the designers feel otherwise. The case is not strong enough IMO.
The weak hard top argument is… weak. Most are built for jumping on. I’m sure there are exceptions, but not the ones I’ve been around. In fact, I’ve made this mistake more than a few times, when I forgot the lift was off and dropped the mainsail. Bang. Not a mark, not a problem. I’m sure it depends on the boat and how far it drops. With Lagoons there is often a big gap. With others the clearance is limited. Personally, I can’t think of a good reason to leave a significant gap.
And of course there is always maintenance. Why on earth would you sail with a topping lift so skinny and so lame that it could break under the weight of the boom? Just poor maintenance. It should never happen.
On chafe, I have to disagree. Yes, I’ve sailed inshore, but I’m not suggesting there was limited chafe on my sails, I’m saying there was none. And you don’t hear about it from cat sailors that go far. They don’t add a rigid vang. Consider that if you have a lot of roach, the topping lift is many feet away from the leach, except for a few inches at the head and clew. Many feet. The motion is different than a mono. They are more likely to reach than run. Lacking widespread evidence, I’ve got to say “no.”
And then there is the matter of lazy jack and chafe. Many pull them, and the TL, forward to the mast while sailing for long periods. An obvious alternative.
I’m not suggesting anything you said is wrong, I’m suggesting it is a different animal.
Hi Drew
I guess we will have to disagree, and that’s just fine.
However denigrating my opinion as arrogant and weak is not. Please have another read of out comment guidelines.
On the matter of chafe it is worth pointing out that I have sailed over 100,000 offshore miles, whereas, I think I’m right in saying you have not. The point I was making that offshore in swell is a different animal too, and given the difference in our experience levels in that environment I would suggest that it would be a good idea to be at least open to my opinion on the matter:
In big swell offshore, multihulls can have (depends on swell angle to heading, hight, and spacing) a quicker and more violent motion than mono hulls because the high form stability of the multi will make it’s attitude conform to the wave slope both front and back, resulting in a quick roll as soon as the wave period exceeds the beam. Of course there are plenty of situations where the mono will have the worse motion too.
Point being I don’t see that multis are somehow protected from chafe.
Perhaps the topping lift is not a problem although I find it hard to see that given that the big roach will surely make it harder to provide separation? But given that the shrouds are swept back on many multis, they will cause chafe, particularly at the battens, if the sail is not kept off them. And that will take either a vang or a tackle to the rail, even on a reach. I think a vang is a better idea, and move convenient, but I’m open to tackles as I said in the article.
That said, it could be argued that the use of a tackle to the rail on a multi is even less desirable than on a mono because the presence of the tackle will make it difficult to dump the main quickly. On a mono that will result in a knock down, on a multi the result could be a capsize. Not something that happens often. (I’m not a multi hater who bends the facts to to fit the argument.)
That said, there have been several capsize losses offshore, particularly at night when the crew was not quick enough to dump the main in a downburst, again something that is far less likely inshore and in daylight since the crew will see the danger coming. Said downbursts can also be a danger to monos as shown by the losses of several tall ships due to down flooding—-poor design and/or handling can get you, regardless of number of hulls.
Of course, as I said before, if the multi is equipped with a full width traveler and designed well enough to sail hot angles efficiently, then a vang would be both superfluous and undesirable.
So yes, multis are different and have many cool features but they are not intrinsically exempt from the dangers that are more prevalent offshore and I still think that some multis could benefit from a good vang.
Sorry about the weak comment. That was only meant as a play on words, but it was poorly expressed. My apologies. As an engineer I guess I make it my business to understand what on my boat is prone to failure, and to either operate it differently, maintain it, or redesign it. For the typical boat buyer that is not a wise assumption.
Regarding chafe, my central argument is that cruiser experience does not support it being a serious problem on voyaging multis. That is all. I understand how it seems that it would be, but it does not seem to be. I’m sure there are multiple factors. I don’t know what they are.
In a blow, a prudent multihull sailor would not have a tackle to the rail. That is only a light wind and slop tactic. He also would not have the vang on, for the same reason; it slows dumping the main. He cannot get instant twist by easing the main sheet.
I am NOT a fan of performance multihulls for off-shore cruising. It is hard for people to comprehend just how fast things can go pear shaped, even experienced sailors, and how difficult it can be to make the required adjustments quickly enough on a large, powered up cat. It can be quite tricky on a beach cat, when you need to bear off in seconds or dump a sail in seconds, and big boats, no matter the crew, don’t respond so quickly. The other problem is that performance cats are only fast when they are powered up, often to a good percentage of the maximum heeling moment. They scare me, and I like performance multis! As you point out, the record of super-performance cruising cats is not enviable, and I believe it is going to getting worse.
The cats that could most benefit from a vang are conservative designs and are sailed much like monos. I don’t fully understand the bias against a vang in this case, unless it is simply that the geometry created by huge deck salons makes it unworkable… which is not a great reason from a sailors perspective. But it is from a marketing perspective.
I once saw 8 jammers in front of a single winch on a cruising cat, and some of these logically would be used at the same time or nearly so. I asked the designer, and he said “it was designed for a different kind of sailer.” I guess one that anchors a lot and motors a lot. Many cats are not designed for sailors.
Hi Drew,
I apologize too for being a bit dictatorial in my first comment, which probably set you off!
Anyway, that all makes sense to me although I still think that chafe will be more of a problem for multis that really sail—good point that many don’t.
The only other thing I disagree a bit on is that I still think we need a vang (or tackle) when reaching off in big breeze heavily reefed (assuming no full width traveler) because otherwise the bottom part of the sail must be hugely over-trimmed to stop the top part from luffing and or resting up against the shrouds. And in my experience an over trimmed main, even part of it, is particularly dangerous in big breeze.
Supporting this idea is that Phyllis and I have broad reached for many miles in big breeze and swell (up to force 8) with just a deeply reefed main and no jib. When people hear that they ask why we don’t use the jib and take the main down, as they do. But in our experience the main in that configuration makes the boat easier to steer and broaches less likely even though the centre of effort is further aft than with jib. I think the reason is that a main, in that set up, does not move around the way a jib does in big swell. But of course we must have a good vang to make that work.
By the way, the advantage of having the main up is that if a course change (say because of a ship) is required, we have the right sail up. Also, we can heave to (probably not a good multi strategy) in an instant without the horrible job of re-hoisting the main when it’s snorting.
I generally agree on not using performance multis offshore…but then if I were 40 again a Dragonfly 40 with the performance rig, or something like it, would be awfully tempting. Or maybe a Pogo. Love fast boats.
Yeah, a fast, fun boat is a hoot. I’ve enjoyed my down-sizing break. And I’ve been thinking about moving back up when I fully retire.
Another difference with cats is that they (should) reef earlier (reef for the gusts, not the lulls). The top does not twist off so much, because if it needs to, that means it is time to reef.
The head sail is barber hauled out much farther, because we can. instead of the head sail shape being a compromise based on the most outboard possible sheeting position, the clew can be hauled way out. On my tri I don’t haul it as far as I can unless wing and wing. This means the jib has less twist (still matching the wind) and is flatter, the main has less twist, and the sails are reefed more deeply. Or at least that is how I like to trim multis. Since I will bear off in the gusts, I don’t want a bunch of twisted off sail head up there, which will power up when I bear away. I would rather be more deeply reefed. The greatest risk on most multies off the wind burying a lee bow, and extra sail aloft is a big risk factor.
I agree re. not taking the main down for a whole bunch of reasons. I’d rather have more reefs. If nothing else, the boat just handles better, and you certainly have more options.
No, I would not heave to for bad weather (to pick up and MOB or other reasons, sure). The cat alternative is to close reach with a tiny jib in very tight and a small main way pretty far out (full battens = no flogging). With trimarans running with a drogue is a better bet, since a breaking wave can push the lee ama under.
Hi John,
I have somewhat mixed feelings on what the correct answer is for boom vangs. Part of this stems from the fact that while I can’t come up with a better solution, vangs are horribly inefficient in terms of loads, the bending loads on both the boom and mast are high from them. Excepting apparent wind machines with long travelers and non-horizontal mainsail foots, I agree that a vang is the best solution when further off the wind. Also, this vang needs to be adjustable both for sail shaping and reefing. Supporting the boom when there is no clew tension definitely needs to be solved but topping lifts can do this although you need to watch chafe as you say (and I am curious to see what your solution is, I know mine and no, it isn’t baggywrinkle).
Where I get caught up is in the implementation. In a perfect cost, reliability and skill world, we would all have hydraulic vangs. But I would personally not recommend considering a hydraulic vang until I was committed to having other hydraulics onboard first. Not many people know how to troubleshoot their hydraulics despite them being pretty simple, people just don’t have experience with it. Also, a jury rig although rare is not easy, you usually need to do a proper repair which means carrying some different tools, fluid, etc. Luckily hydraulic hoses can be made at most ports in the world but they are not something I would expect anyone to make at sea. And I have had my fair share of hydraulic leaks, everything from a few drips from a fitting to fully blown hoses. I can assure you that I was not a happy camper when we were sailing off the hook with the anchor just off the bottom and I looked up to see all of the crew that had been on the foredeck lying on the deck midships flailing as we had developed a hydraulic leak and the deck was now coated. Needless to say, I sailed around in tight circles for probably half an hour before someone could get to the windlass and use the manual override, most boats would not have even had enough paper towels and cleaning product on board to even deal with it so would have had to create a giant environmental disaster too. While an extreme example, hydraulics are generally good and reliable but don’t have great failure modes. My hang-up here could probably be summarized as hydraulics not necessarily fitting with “attainable” as great as they otherwise are.
At the other end of the spectrum, you have a super simple block and tackle. Other than not holding up the boom, it meets the other requirements as afterall, a mechanical vang just adds the spring cylinder. Yes, they can be a bit sensitive on adjustment and they need a cascade on bigger boats but they do the job. If I were cost conscious, not on a big boat (I would hope not if cost conscious) and not planning a lot of offshore work, this is definitely a reasonable way to go in my opinion, there are many other places to spend money that may be better for safety, speed, whatever. Offshore, I still think it would be reasonable but you would need to deal with chafe, I have experience with it and frankly it was never enough of a problem that I ever noticed.
So is the mechanical vang a good middle ground for mid size boats going coastal or small ones going offshore? Maybe? Honestly I haven’t sailed with one setup in such a way that you can fully ditch the topping lift and without this, as long as you setup the topping lift to be easy to adjust, I really don’t find they offer much more than a block and tackle. Given the pricing and reputation of Garhauer, it might just be worth it although I haven’t used one of their units.
Your point about needing to get the attachment points right is spot on, many are scary in their implementation. The loads are high in all of this and there is a reason why failure of the attachment, failure of the boom at the vang and failure of the mast at the gooseneck are so common with the vang being a major contributor. I won’t deny that a hydraulic vang can be quite nice and the mechanical ones are handy too but I don’t see them as being critical in the way that making sure your rudder hasn’t deteriorated or that you have good ground tackle are.
Eric
Hi Eric,
Very good point how mechanically disadvantaged (is that a thing?) the vang is. Maybe the most of any assembly on a boat, at least a cruising boat.
That said, I have had solid vangs for 40 years (was an early adopter) and while I have broken one, that was early days and self inflicted—having the full main up and running off whooping and hollering, instead of reefing, in a 50 knot line squall (racing) is not smart—they have been very reliable and I can’t imagine being without one, particularly on a short handed offshore boat.
The other thing is that, at least in my experience, the hydraulic rams on yachts—Navetec in my case, three of them—have been extremely reliable and when they have failed—twice, the same backstay ram—it was a slow leak at a seal that did not get markedly worse for the three months it took to find a Navtec technician. Just tied a rag around it.
I would disagree about this kind of hydraulics being difficult to troubleshoot. At least in my experience, both on my boat and on race boats before that, the few problems have been simple slow leaks. Also the hydraulic ram and pump system on our autopilot has been incredibly reliable and is simple to rebuild—I have done it twice myself.
That said, we do carry seal kits and have a plan in in place in case any of the four rams on the boat blow a seal:
We do carry some spare hose and fittings (never used), but the good news is that most anywhere has a shop that can make up hoses.
All that said, I do agree with your last sentence.
Hi John,
I realize that I probably wasn’t clear enough that I do really like using hydraulic vangs for the reasons you list, I just would find them hard to justify for many boats in a resource constrained environment. If I were outfitting a 50’er that I was putting a few hundred thousand into, it would have a hydraulic backstay and vang, that is an easy call. However, if I were outfitting the mythical $100k 40′ offshore cruiser, there is no way at all that it would have these unless the boat already had them and they were in decent shape as starting from scratch would eat up a minimum of 10% of the budget when you can have a perfectly acceptable solution for 0.5% of the budget.
There appears to be a slow shift away from hydraulics in many applications that is starting. This shift seems to be due to higher level systems thinking in the design and efficiency considerations. Electric systems tend to be much more efficient than hydaulic ones which then means the powersource (often a diesel) can be much smaller as well (the term hybrid is thrown around a lot here and both systems are often configured as hybrids but the reason is the number of functions needed and their intermittant nature). Given the cost of doing this, it tends to be in high power and duration applications (dozer drives, groomer drives, excavator swing, etc) or high performance (robotics) ones for the time being. This doesn’t really apply to vangs or backstays as the power input is human, there is no need for more efficiency and simplicity and reliability are king. Where I am interested in is autopilots as they are such a driver of energy consumption and they are not all that efficient either. I know of several people who have bought an electric CPT as a backup and then ended up using it as their primary for this very reason. There are good reasons why electrically driven hydraulics have traditionally been used but straight electric drives have some compelling reasons to consider them. If autopilots drop hydraulics at any point, then in my mind it would be harder to justify them in other applications for a lot of people due to the need for carrying spares, learning about how to troubleshoot, etc.
Eric
Hi Eric,
I agree on autopilots. When I bought MC she had a massive electric motor actuator and it worked great. However that died and the company was no longer in business, and at that time the only way to get something reliable was hydraulics. And indeed it has been fantastically reliable >80,000 miles without a failure and very little maintenance. However I’m now seeing some interesting looking electric drives again, so if starting from scratch I would look at that.
Question: I am interested in fitting a ridget vang – but the foot of the mast is cluttered, with electrical cables exiting right where I have seen some boats mount the vang.
Does it work to mount the base of the vang a few inches *behind* the mast – onto the deck? I can handle the loads, this is a steel boat – but does the geometry and forces work, since it is no longer quite a triangle.
Thanks for any thoughts.
Hi Richard,
No, I’m reasonably sure that won’t work. As I understand it, for a ridged vang to work the pivot point needs to be in the same relation to the mast as the pivot point of the boom. If the pivot point is aft, as the boom is let out the vang will pull the boom further down.
Hi John, my 1983 boat, Pan Oceanic 46 (Ted Brewer’s design), did not come with a vang. It has a topping lift and a boom gallow. When I bought the boat used, the previous owner mentioned that if one is sailing the trade winds round the world, there is no need to rush and trim the sail as if racing. Hence, that is the reason that the boot was sold without a vang. I do not have enough experience in the big seas and wonder if one can get away without a vang. So far so good in South East Asia.
Hi Ee Kiat,
I have heard all kinds of excuses for not fitting a vang, but that’s a new one and one of the least well reasoned.
Actually sailing in the trade winds is a time when we need a vang most since we will be down wind a lot of the time and without a vang the sail will twist off and rub against the shrouds. Excessive twist is also inefficient and tends to result in over-trimming the lower part of the main which makes the boat hard to steer.
The only alternative without a vang is a tackle to the rail, but that has dangers: https://www.morganscloud.com/2018/10/02/amidships-preventers-a-bad-idea-that-can-kill/
The bottom line is a vang is one of the basic sail controls that we need to sail our boats well.
Thank you John. Let me see if I can fit one in following your guidelines above.
