Let's assume you want to go voyaging and have just bought a new boat with no electronics at all. First let's deal with communications:
Marine Electronics Recommendations—Communications
by John Harries
Reading Time: 6 minutes
Next: HF SSB Radio or Iridium Satellite Phone?
Previous: 6 Tips To Stop Marine Electronics From Ruining Your Cruise
- Knowing Where It’s At
- Three Electronic Charting Dangers That Can Wreck You
- Keeping Safe From Chart Inaccuracies
- You Still Need an Accurate Compass
- Chart Plotters And Autopilots, Never The Twain Should Meet
- Do You Still Need Paper Charts?
- Backup Systems, Do We Need Paper?
- 11 Tips for Safe Navigation With Phones and Tablets
- 12 Electronic Navigation Tips From a Cruise on Someone Else’s Boat
- Marine Electronics System Recommendations
- 6 Tips To Stop Marine Electronics From Ruining Your Cruise
- Marine Electronics Recommendations—Communications
- HF SSB Radio or Iridium Satellite Phone?
- Marine Electronics Recommendations—Radar
- Which is Best For Navigation: Plotter, Computer or Tablet?
- Our Navigation System
- The Best Windows Computer For Navigation
- Q&A Which Sextant To Buy…If At All
- The Secret Life Of Your GPS
- Coastal Passages, Part 1—Making a Plan, 10 Tips
- Coastal Passages, Part 2—Rounding Headlands
- Coastal Passages, Part 3—Off We Go
- Costal Passages, Part 4—Keep On Plugging
- Coastal Passages, Part 5—On To The Finish
- Passage Anchorages
- Navigating in Fog, Part 1, The Tools
- Navigation in Fog, Part 2—Preparation
- Navigation in Fog, Part 3—Underway
- 8 Radar Use Tips
- Integrating and Documenting NMEA 0183 and 2000 Networks
Share a Link
John was born and brought up in Bermuda and started sailing as a child, racing locally and offshore before turning to cruising. He has sailed over 100,000 miles, most of it on his McCurdy & Rhodes 56, Morgan's Cloud, including eight ocean races to Bermuda, culminating in winning his class twice in the Newport Bermuda Race. He has skippered a series of voyages in the North Atlantic, the majority of which have been to the high latitudes. John has been helping others go voyaging by sharing his experience for 25 years, first in yachting magazines and, for the last 20 years, as co-editor/publisher of AAC.
John,
when talking about costs, your solutions isn’t so terribly expensive. Sure compared to semaphore flags and a morse-mirror, the thousands hurt. But comparing those to the cost of fully integrated and networked navigation suits, getting dedicated pieces often turns out to be the cheaper solution, even if it’s only because you pay for less features you don’t need.
Around the topic AIS and VHF, I found two more things to consider:
GPS-receiver: Although many appliances have integrated GPS, having at least one external GPS-antenna is probably a good idea. I ended up attaching a mushroom-antenna to my AIS and have the transponder then distribute the data-stream to the other appliances via NMEA-0183.
VHF-Antenna: Two antennas on the mast(s) or an antenna-splitter? The second option are another $200 or so, but there is one less cable going up a mast.
Perhaps it’s worth mentioning for those just wanting passive AIS to look at a VHF with integrated AIS-display. That saves all the hassle with the antenna. By the AFI-philosophy the Icom M506 would be the preferred good choice.
Hi Jo,
Good point on the antenna splitter, or not, issue. We are currently using the Vesper antenna splitter, but based on our experience with that I would recommend fitting a separate, and separated, antenna for the AIS transponder. Despite Vesper claims to contrary, we often, but not always, get a click on the radio when the AIS transmits—very irritating!
Given that problem, I do worry that the antenna splitter may be adversely affecting the VHF, although I should add that we did test with an output meter, with and without the splitter and were not able to measure a difference.
In our case I think we will install a separate antenna for the AIS on the radar stand, which will give it a bit of hight, but still give us plenty of separation from the VHF antenna on mast.
Hi John,
During the last ARC we used Iridium Go, mounted below deck with an outside antenna. Having read a lot of other users’ complaints regarding this device, I was really afraid that I would not be able to communicate with the organisers and other people and. to download forecasts (MformthismImusedmthenOcens Grib Exploer Plus for iPad). On the contrary the Itidium Go worked for me.
I send and received e-mails (text ones) and tiny compressed pictures). With the Grib Explorer plus I was able to weather route our boat. The only problems I encountered were: 1. When using for voice calls – you need always to be logged in on your smart phone in order to get rings also from it when someone calls you, otherwise when you hear only the device ring by the time you log in, an automatic answering machines switches on and you lose the opportunity to receive the call (may be it is a matter of settings of the automatic answers); 2. When you send messages, each time a message was sent, I was logged out. Fair to say that log in on my IPhone 6+ took only a few seconds. Same story with IPad. Nevertheless, I was quite satisfied with the device . It never failed. Form time to time it loses the sattelite connection and then it emits a particular sound, which stops when it finds it again. This happened often (several times per 24 hours) but I am not sure whether it is a fault of this particular device (the Iridium Go).
I believe that the Iridium Go is the future way to go and sure there is a way to improve the applications. In theory if you lose the will-fi connection or the applications get bugged, you have no connection but it never happened to us. If you lose your only phone/tablet with downloaded applications, the Iridium Go becomes useless, but on board normally there are a few smartphones/tablets.
Hi John,
I enjoy your acronym, AFI, and fully agree its message. Icom’s service life always exceeds my wish to get some new capacity; this time leading me to exchange a fully functional 15 yo unit for one that had push button DSC alarm capacity (ICOM M604 radio) and integrated seamlessly with my ICOM MA-500TR (AIS). I have used the AIS unit now for 2-3 seasons in the crowded waters of Northern Europe and in some North Sea passages and found it to do all I wish it to do. (In addition to all AIS functions, it also allows you to turn off the transmit capacity, something I wish more recreational vessels would do when in the crowded waters like the Solent- and even more so when they return to their marina.) I notice commercial vessels making small adjustments to their courses 4-6 miles out and passing at a reasonable distance and my need to make radio contact is much reduced. I suspect they are happier as well as interpreting a swaying bouncing tricolor from a distance has to be work. Much easier to get course/speed/bearing data to work from.
I do not use DSC very often and therefore do not have its use ready at hand in my head when needed and must go to the radio’s directions. However, I have used the function you queried about first hand and it is marvelous. No memory of DSC usage is required nor is there need to access and then program their MMSI number: just highlight the vessel on the AIS (something done all the time anyway to collect info) and initiate contact. I have rarely used this as commercial vessels in this part of the world are well behaved and generally predictable, but one or two whose intentions were unclear got my DSC blast and answered forthwith. Badda bing badda boom. If technology is to make life simpler, then this combo succeeds.
My best, Dick Stevenson, s/v Alchemy
Hi Dick,
Thanks for the confirmation on that feature, sounds great.
Hi again,
Our AIS antenna is on our pushpit which gives me all the range I want. Commercial vessels (with their high antenna location) come in 12-15M out and I have never felt my AIS functionality compromised by its lower location. This location has a number of benefits: easier installation and troubleshooting, less clutter on the monitor, no need for antenna splitters, which, I believe, need to be powered by the DC grid to work, and (maybe) some redundancy for a lightening hit.
When planning the coax cable runs, I suggest having cable connections in one location. This demands extra cable length for some runs (not an issue if you buy good cable), but the benefits are worth it. You can then easily swap the VHF from the mast head antenna to the pushpit antenna if you lose the mast or take the mast down for canal transits. (For us the coax is from a below decks VHF, a cockpit VHF and an AIS. For ease of swapping an A/B or an A/B/C switch is helpful: there is no need for a splitter and its complications, but do buy a good quality switch). Finally, there is no need for extra fittings at the mast head to give the antennas adequate separation.
My best, Dick Stevenson, s/v Alchemy
Hi Dick,
Great recommendations, I totally agree.
Our decision to go with an antenna splitter was a mistake that we will rectify in the spring in the way you suggest.
John,
Amen to the tried and true model that is not connected to much…
+1 Icom radio, ours is great
+1 Iridium SatPhone, not hard to setup data transfer and for our style of crusing (off and on intensive use of sat phone then very little when coastal crusing). We ended up with X-gate compression service, works fine, awful email interface, but is easy to use on the mounted iPad when at sea for downloading GRIBS.
+1 for Furuno FA500 AIS displaying on a Furuno 1835 Color Radar (with ARPA option) having all the collision avoidance data on one screen is pretty great when you have a mix of targets broadcasting and not broadcasting AIS data (like two nights ago in the English Channel)
+1 to seperate antennas for VHF and AIS, we lost 70% of one in a lighting storm and we’re happy to have the other ready to switch over if/as needed. I like Dick concept of separating them (ours are both up the mast).
Christopher
Hi John,
Re AIS, the SE Asian perspective is that both Singapore and Thailand (Phuket) now require an AIS transmitter to be fitted (and working) as a mandatory requirement for entry, and while not mandatory t this time, Australia’s Border Force has told us informally that they investigate all vessels coming from Asia as a matter of course if they are not transmitting an AIS signal. No doubt as the world progresses further in becoming a less safe place for all vessels we will see this being a continuing trend.
That said, and having made several transits of the Straits of Singapore and up/down the Malaca Straits in the last 18 months, AIS is a mandory safety requirement (both transmtting and receiving) in my view. It makes everyone on board a lot happier to know that vessels from tugs towing barges at 3 knots to 300 K ton LNG tankers travelling up to 22 knots can see us and we can see them in terms of heading, speed and likelihood of collission.
re. The Vesper AIS unit we run it it has given good service sans a firmware issue that the Malaysian agent helped me fix wth little drama. We do run an arial spilitter and have lost a unit due to an electrical storm which meant either no AIS or no VHF until it could be replaced – again from the Malaysian Agent with no drama. The splitter will go as soon as we can organise this as electrical storms in this region are common and we can not afford to loss our AIS.
A consideration that emerges out of this experience (and yours re Vesper) when investing in electronic equipment is the capacity to source repairs or replacements. Particulary when operating in parts of the world were remoteness and none english speaking government utilitie like Kustoms can present critical challenges.
Hi Tony,
I think you are right that more and more governments will start requiring AIS transmission, and in addition, even in countries that don’t, border authorities will look with suspicion on any yacht that does not transmit.
For example. I believe I’m right in saying that AIS tracking is part of US Homeland Security’s strategy already. We were in the USA for much of the time our Vesper AIS was defective and one of the symptoms was that it would intermittently stop transmitting. All I could think or was the suspicion that this behaviour would engender in a border protection member!
We bought our Iridium GO thru PredictWind (fulfilled by Atlantic Telecom) and their instructions and support made setting if up pretty easy and straightforward. The unlimited data and unlimited SMS is invaluable (however the Iridium SMS sometimes goes on a walkabout). PredictWind provides very good support by email and if needed will call you back by phone and walk your thru things. And they include the ability to ping a personalized tracking webpage hourly with our GPS position.
PredictWind by internet has been great, but downloading via the GO is quite slow. However animating the GRIB in the PredictWind Offshore app is invaluable and makes it very understandable and easy to analyze to make weather routing and departure timing decisions.
I agree with you on the OCENS weather bundle, but some of OCENS new smartphone apps for Iridium are great and pretty inexpensive. The GOs SMS is not private, but OCENS OneMessage via the GO is. OCENS OneMail lets you review headers and selectively download mail from your gmail account. OCENS SpotCast with WaveCast give quick 3-day text weather, wind and wave reports at our coordinates (or any that we specify). OCENS support has been great. I correspond directly with one of their executives, and they have fixed and updated their app in a couple of days when I reported a bug.
We got the Vespers XB-8000 blackbox AIS transponder and splitter. Installation was pretty easy, it has functioned flawlessly, and displays on a smartphone or via wifi or NMEA or a wide range of other devices.
Hi All,
Thanks very much for all the great suggestions and real world experience—always the best kind—please keep it coming.
Dear All,
Interesting and inspiring article, John !
I have used the ICOM MA-500TR AIS Transponder since 2011 on a 3 year trip round Ireland and now 2015/2016 on the Norwegian West Coast, with success. The unit came with its own bulky GPS receiver, but with ICOM UK’s good help, I had it converted to accept the GPS signal from the Nexus NX2 Server via RS-232.
Using a separate VHF aerial (for redundancy) situated on top of our open doghouse gives safe coverage to follow other vessels, however, shore based stations are only picked up in closer proximity. This means that AUK cannot readily be followed by Marinetraffic.com.
Occasionally we get an ‘ANT MALFUNCTION’ error message, but I have been unable to trace the reason for his.
The next project is to install a dedicated 12V solid state PC permanently in the chart-table for running OpenCPN with two 15” monitors, a fully dimmable one in the doghouse and a simpler one on the chart-table. The AIS will be interfaced to this PC. The reason for opting on OpenCPN is that I like to have a choice on my electronic chart supplier.
Kind regards,
Niels
s/y AUK, OE32
Hi Niels,
Was there a reason, other than the bulk of ICOM’s GPS antenna, that you discarded it and got GPS input elsewhere? And was it a complicated adjustment or not so hard after it was figured out? If possible, can you give an idea of what needs to be done? It is always nice to have alternatives and we already have a Furuno GPS unit bringing in GPS data.
We head for the west coast of Ireland next season.
Thanks, Dick Stevenson, s/v Alchemy
Hi Dick,
I did not see a reason to mount another GPS receiver on the boat; the Nexus GPS and the standalone Koden GPS already gives me redundancy. The ICOM AIS unit was sent to ICOM UK Ltd. who did the modification. After that it was a matter of finding the correct wires to link up and that was no big deal. Good luck in Ireland and do not forget to call into Inishbofin and Clifden.
Niels
Hi Niels,
Thanks for the info. Clearly not a swap one does in the field. thanks for the cruising suggestions.
My best, Dick
Hello John,
I’ve been having a long hard look at the Iridium Go and I like what I see, in spite of there being a lot of complaints about it not being usable for Internet. All I really care about is being able to download mail, send text messages and be able to make and receive calls.
From your warning it sounds like you need to be very tech savvy to set it up. What were your key difficulties/obstacles?
Rumen’s experience sounds positive and similar to how I would use it, so I’m optimistic again about the Go. This was not the case after emailing GroundControl.com, because they suspended sales of the Go after receiving too many complaints. Here’s what they said: “Customers are complaining that the Internet service does not work, which it doesn’t really… and as such, we were taking the brunt of customer complaints even though we had no control over the network.”
Not a big problem for me, since that’s not why I’d be getting the unit … and hopefully it will improve when they upgrade their network next year.
Best regards,
Andreas
Hello Andreas,
If by internet service, it is understood broswsing, it does not work but I think this is not a short coming of the Go only. They should not have included “Web” in their “Mail and web application’, therefore I never used the icon “web”.
Rumen
Hi Andreas,
I can’t really list specific problems, because in the end I got the GO! working the way I wanted it to and it didn’t take me that long. However, having spent a lot of my life in the computer support business, I could see that the process and the product are rife with opportunities for trouble, hence my warning.
So, as I say in the post, only you can decide if you want to take the GO! on. Having said that, assuming you get decent support from the dealer, I would expect that you will get it working eventually, just make sure you leave plenty of time to fuss with it before you need it and test the heck out of every function before you go.
And yes, I think a lot of the reason people hate the GO! is that Iridium was not clear enough about its limitations and therefore many people buy it on the assumption that they will be able to surf the internet, which, of course, they can’t. (You can request any page from the internet as long as you know the URL.)
Hi John,
I’ve had a number of friends and customers upgrade their legacy instruments lately, some due to need and others have done so for the new features of AIS targets on chartplotter and Ipad connectivity. I’ve taken a different approach on our boat – taking the AIS and GPS output from the Vesper AIS receiver ($300 standalone unit with display) and hooking it to a RS232 to Wifi adapter. Running AIS compatible software on the computer or tablet it is an easy setup then have your device connect to the wifi. Outlay is software ($0-$400) plus adapter ($50-$100). We still have our legacy standalone systems that we’re happy with and have added AIS targets, weather and current information, etc. on the tablet and laptop. Far better than the 5 figures that is often spent.
Agree with Dick on the separate antenna. Also everyone should have on board an adapter to connect their handheld VHF to masthead antenna – 5 watts from a high gain antenna 60′ up has surprising range.
Cheers,
Keith
John,
Very nice article! I agree with a lot of what you said, but not surprising not everything.
After purchasing Surprise in 2013, I updated the electronics. I replaced the original VHF with the ICOM M604. Good radio, main reason for getting it was for the keyboard for the reasons you pointed out. My only complaint was that the connectors to connect it to NMEA was really a kit and soldering wires to the tiny pins was a real pain. I would have expected better from ICOM.
Surprise came with an excellent marine SSB and separate HAM transceiver (both ICOM), backstay antenna, antenna switch, single antenna tuner, and Pactor modem. Other than having to upgrade the modem, all has been great. I like radio, have a ham license (KI6ASK), and am a long time sailmail user.
I installed a Vesper XB-8000 AIS Transponder, antenna splitter (using top of the mast VHF antenna), and separate WatchMate display. This is connected to the boat computer (USB) and to the ICOM VHF (NMEA). I like the ability to make an DSC call from the WatchMate. [I wish the NMEA sentences for this were standardized, so all chart plotter software could have this feature, seems to be an ICOM thing at the moment.] It’s been reliable system, but the NMEA wiring was a project. I have seen tracks using MarineTraffic, this was especially nice when I had the boat delivered from Santa Cruz to San Francisco. Was very nice to see where the boat was off the coast of California. I assume from this I am putting out a good signal.
On a related topic, I installed a semi-custom industrial computer from Logic Supply. It run on ship’s power, no fans, SSD disk, or any moving parts. It’s been fast and reliable, and low power. All great for a boat. Happy to provide more details. Computers on boats would make for a good article.
Currently, I am considering upgrading my original Iridium phone to the Iridium Go or the Extreme model. I would use Sailmail with either. Based on your article I am leaning to the Extreme, The issues I see with the GO are having to use WiFi to connect to the computer and I think the Go wouldn’t be a good choice in a life raft. On the other hand, the price for the SIMs for the GO are more reasonable, I really hate buying Iridium time and having it expire. Another tradeoff.
Hope this is useful.
Bob
It’s very useful to me, because it aligns closely with what we wish to do in our two-helm, pilothouse nav/comms setup. The fanless PC would suit me down to the ground. The only question in my mind is whether to double up with a simple, stand-alone plotter at the outside (“sailing”) helm or to have a waterproof “repeater” screen to see the output of the below-decks nav display. I’m glad you like the Vesper gear: I’ve found reports of it impressive.
My Vesper AIS has given me no problems and has been a real asset both crossing the Atlantic and in the Med. I understand your reluctance to recommend it since you had a hassle with the company, but fail to understand why you would recommend a unit you have never tried. Better, imho, to ask for feedback from others on both systems.
Hi Raymond,
See Dick’s comment below. For me, the big problem with Vesper was that they refused to replace the defective unit and made the whole issue my problem. Further, they have no service facilities outside of New Zealand—or at least did not at the time—contrast that with Icom that have service dealers all over the world. No amount of feedback on the Vesper changes those two facts.
Hi Raymond,
I suspect the answer is embedded in the AFI acronym and John does ask for feedback after acknowledging a lack of first hand knowledge. Like so many of these marine electronics products, once they are working and figured out, they often give good service. My ICOM AIS MA-500TR was good out of the box and almost plug and play in the set-up/installation. That is a good deal of what I look for in a product after determining the likelihood of good service.
Dick Stevenson, s/v Alchemy
Hi John,
I am curious as to how much of your gear you have doubles of or repeaters for so that they work both on deck and down below? Since this post is about communications, do you have 1 radio, 1 radio with a RAM mic, 2 radios or something totally different? On our last boat, I mounted our radio right at the companionway so that it worked reasonably well on deck and down below. Our current boat has a single fixed radio down below and we use a handheld in the cockpit which is not ideal. I have been thinking of going to a RAM mic for the cockpit but it hasn’t yet made it up the priority list. I have used this system on a few boats and it is okay and probably a better compromise for me than 2 radios and the associated antenna issues. We do definitely use the radio both up on deck and down below and it is very dependent on where we are sailing and whether we are underway or not.
Eric
Hi Eric,
Good question, I should have covered that.
As you know, the radio itself is mounted on deck. We also have a remote command microphone below so that we can monitor and use the radio when at anchor. Like Dick, the volume on the RAM below is always kept at zero unless we are using it.
We like having the main radio on deck because it’s much easier to operate, particularly when tired, than the RAM mike.
We also have an ancient (30 years) ICOM VHF below as a backup. It’s arial wire terminates at the mast joint for the main radio, so in the event of needing it, we just disconnect one radio and connect the other.
I think, based on our own observations and Dick’s comments earlier, we will change the whole setup by moving the AIS to a new antenna on the radar stand and use the splitter, which we already own, to share that antenna with the spare VHF. Or maybe we will just end up with an A/B switch like Dick.
We also have a hand held VHF.
Hi Eric,
I know you were directing the question to John, but I thought I would step in w/ Alchemy’s set-up and a comment about the set-up that many have not considered. We have 2 VHF radios, 1 in the nav station (in actuality rarely used) and 1 in the companionway just before exiting, both sharing the masthead antenna with an a/b switch (not a splitter). The companionway radio has a RAM in the cockpit near the helm. We find this important on passage, especially coastal overnighters, as we monitor ch 16 at all times and if either of the below decks radios is on, the talking is hard not to pay attention to and disturbs the off watch crew sleeping. The RAM is heard mainly in the cockpit where the on watch person is the bulk of the time and does not disturb the sleeping crew below.
My best, Dick Stevenson, s/v Alchemy
Hi Dick,
Thank you for the thoughts. I agree completely about not having a radio on below decks when there are off watch crew asleep. I have occasionally forgotten and left the radio at our nav station on and then had to crawl out of my comfy bunk to turn it off. I find the radio below is really only good when we are not underway but then it is really nice.
Your solution of an a/b switch makes sense, I really don’t want to end up with a splitter. It seems to me like whether a switch is used or a single radio with a RAM mic, the key is that most of the radio work is from on deck but you do still want the ability to use it down below.
Eric
Hi Eric, I’m not sure what kind of switch Dick is using. I have upgraded some of my ham and marine switches to the Alpha-Delta brand (model 2-b). They have a built in and replaceable lightning surge protector and you can ground the radios by moving the switch to the center position (unusual switch feature), also the unused radio is always grounded. I’ve had cheaper switches wear out and not have the added features so I upgraded a couple of switches last year, I got mine at DXEngineering.
Hope this helps,
Keith
The only thing I’d add is a few Uniden Atlantis 250 handheld VHF units.
For under $100 each, they have excellent range and quality for a handheld (I routinely get “5-by-5” on radio checks to a station 5+ NM away), are durable and reliable, don’t seem to have any flaky-charger issues, and can run on a pack of AA cells if you run the lithium battery flat and have no way to recharge it.
Hi Keith,
Excellent addition to the recommendations. I am using a Ham quality a/b switch (not the a/b switches that are sold at the usual recreational marine culprits), whose name escapes me–but likely suggested by you in years past.
My best, Dick Stevenson, s/v Alchemy
Hi John,
Having an Iridium 9505 handset I found using it a real pain with lot`s of dropped connections.
I then went to a Sailor SC 4000 fixed unit and had great connections.
This unit costs US$2200 and will save that in usage fees. While data is slow we used the free grib files that come with Maxsea and that was very efficient. SMS messages are 60c
Aerials are now to be hidden in the boom gallows timber beams
Regards,
Bill Koppe
Hi Bill,
Interesting, I have not had that problem. Where you using an external antenna with the 9505?
Hi John,
Yes used the external antenna.
Regards
Bill Koppe
Hi Bill,
I’m guessing either a bad antenna or cable. I have been using the Irdium hand sets for some 14 years now, without excessive drop out problems. Of course their are occasional drops when the satellites are not in the right place. The other thing I have found that really helps is to use UUplus because their software copes really well with taking up after a drop without loss.
Hi John,
Thanks for the advice and the UUP Plus tip
Bill Koppe
Many traditional SSB radio functions are partly replaced by satellite systems, but in many parts of the world SSB nets are great tools for cruisers.
In Northern Europe we did not find any active nets, but there are many good ones further south, Caribbean and Pacific
We have a low-end ICOM HAM & Marine radio and tuner and consider them worth the cost. ( both replaced troublesome equipment from competitors)
Hi Neil,
True, I deal with that trade off in depth in this post.
John, my son and I are updating systems to go offshore. I figure I can use AIS, since I use radar and chart plotter now. I have to say however that I am quite concerned about my ability to get everything set up with sat phone and whatnot in order to receive weather. I am kind of a Luddite, or at least an old guy with some computer phobia. I don’t carry a computer on board but it looks as if that will be necessary for weather maps. Can I get a laptop that runs on 12 volt? How do I hook it up to a sat phone? How do I learn how to run the wire and set up an external antenna? In sum,where can I go to start getting an understanding of the basics of how to set things up. You and all the others commenting seem so knowledgeable that I feel overwhelmed.
Valuable analysis as I select an AIS Tx solution, thank you. I now think to ft the Vesper XB-8000 black box, integrated to our Zeus2 at helm.
I found this linked content of considerable interest, which highlights the common geaneology of AIS units across several brands:
http://continuouswave.com/whaler/reference/AISB.html
Neil, S/Y L’escale.
Hi Neil,
I’m glad it was useful. One thought for you: I’m not generally in favour of black box units for any function and prefer those that are a complete solution in one box. The reasons are better ease of use (sometimes) and better fault tolerance (near-always).
(I’m thinking about an article on fault tolerance.)
Coming back to this: I just got off the phone with U.S. marine goods sellers Defender.com, who seem a decent outfit. I’m considering buying the Vesper XB-8000 Class B AIS transceiver from them (I think Vesper have improved, John, and this model has a number of desirable features for me). On the page listing the Vesper, I noticed that they won’t sell them without inputting an MMSI number and that some sort of FCC compliant must be filled out, along with a fax of one’s MMSI number. Fair enough, and they said they could input my Canadian-issued MMSI at their end, as they are required for American reasons to do.
But, needless to say, I can see a number of ways for this to screw up.
Has anyone in Canada actually bought an AIS from Defender and had it arrive with the correctly input Canadian MMSI number? This would reassure me, as the operator on their 1-800 customer service line had not had the question posed to her before and had to “call the president” (of Defender, I assume, not Mr. Trump) to answer my question in the affirmative. So anyone out there try this yet? Thanks. I realize this is an unusual comment, but the odds are quite good in this crowd of passage-making early adopters that someone has encountered this issue.
Hi Marc,
The reason they are insisting on programming the MMSI is because you are buying it in the USA. Buy one in Canada—as I strongly recommend—and you won’t have this problem, it’s a US Homeland security requirement.
Also, if buying Vesper check where service is performed. See above post.
I still recommend Icom.
Thanks, John. I have more spare U.S. than Canada dollars at the moment (a good problem to have, I guess) and was looking to spend them. The Vesper service check is duly noted.
Hi John,
you mention using a combination of Iridium + SSB receiver. That’s a combination I like because it provides some sort of redundancy for weather info (and because I have an Iridium phone already..) I was wondering if I could ask you a couple of questions…
-Does the radio receive signal just as well as a normal SSB transceiver? And Have you tried one in more confined environments – like a Patagonian (or Norwegian maybe in your case?) fiord? Can I rely on it for weather info – considering the Iridium is there as a back up for the occasional misconnection?
-Will it require a modem pactor and sail mail to download Gribs, Synoptic charts and… emails (is this asking too much?)
-Will it require an external antenna and other hardware (demodulator) and if so could you advise a brand? (I have two spectra running backstays – no backstay to use as an antenna)
-As for the Iridium, you mention that for it to work at its most, I would need an external antenna , is there one you’d recommend?
-Does the Iridium require a modem pactor to send/receive emails and get gribs + weather maps?
As you can probably tell, I am definitely not a techie…
Many thanks!
andrea
Hi Andrea,
In the post above, I’m only suggesting the SSB receiver for getting weatherfaxes and then only for those who opt not to go for a GO! with unlimited data. And no, I have not tried this receiver. And yes, it would need a good external antenna to work well.
Given that you are not a techie, I would recommend the GO! and unlimited data over any SSB alternative. Way easier to deal with: We have a step by step guide on all of that in our weather Online Book: https://www.morganscloud.com/category/weather/book-weather-analysis/
And no, the Iridium does not need a pactor, it’s a native digital device, unlike a radio which is analog and therefore needs conversion. We have two chapters in the above online book that explain all about the GO! and what you need and don’t need:
Thanks!
Yep, go seems nice, though the monthly cost including sailmail or UUPlus seem a bit steep.
Any chance you have a rough idea of how much downloading gribs via handheld iridium May cost (I know it would be a rough estimate!)
Thanks
A
Hi Andrea,
See this chapter:https://www.morganscloud.com/2011/11/17/weather-system-gribs/
Thanks!
Can you recommend a particular vhf aerial suitable for aluminium hull. I know some manufacturers need a dc block fitted to isolate the screen.
garry
Hi Garry,
Sorry, I have never seen a VHF antenna with an insulated mount. That said, it’s fairly easy to fabricate one using insulating washers and sleeves. We have two VHF antennas, a cell phone amp, and WIFI all insulated in various ways. Mccmaster Carr is a great source, if you are in North America, of plastic bits and pieces to make this relatively easy: https://www.mcmaster.com
Tell me a bit more about your situation and I might be able to make a specific suggestion.
John,
I have a spare masthead METZ aerial that I can use. It does work, i’ve tested it with my existing vhf, but not with an SWR meter.
I get an earth leakage fault on my meter when I connect it to the VHF. I initially though that the cable had frayed and exposed the sheath which was touching the mast. I’ve examined the cable entry into and out of the mast and there is no visible signs of damage, Though possibly it could be frayed within the mast, but I thought that would likely show up as an intermittent problem. The Metz guide shows that there is an internal loading coil which manifests as a DC short across the coax. This is what I’m guessing is causing my problem, but I may be totally wrong, and there might be exposure of the coax sheath within the mast, hence the query.
thanks
garry
Hi Garry,
When you say leakage fault on your meter, I assume you mean the meter that shows stray current from the electrical system to the hull. And that when you disconnect the antenna cable from the VHF radio that leakage goes away?
If so, the answer is simply that either the sheath of the cable is touching a metal part connected to the hull, or the body of the aerial is. The coil in the METZ is not the problem since all that is doing is showing a short across the cable, but it has no way to complete a circuit to the hull without something touching.
So, first thing to do, is leave the radio end connected and then disconnect the antenna. If the leak to hull goes away, it means the antenna is not properly isolated from the mast (my guess), if not, the cable has chafed somewhere and needs replacing.
Note that the case and mounting of METZ antennas, like all whip antennas I have seen, is not isolated from the sheath and therefore to maintain an isolated system the antenna must be isolated from the mast.
By the way, the lightning arrester you link to will almost certainly not solve the problem.
Hi. Regarding AIS, there is now a “new” one, called SOTDMA, or Class B+. It is not really new, both in the sense that its now several years since it was introduced, and that SOTDMA have been the way Class A transponders have communicated for a longtime.
For sailboats, I se only two potential benefits: wattage increased from 2 watts to 5 watts, and guaranteed transmission slot (maybe valuable in a very busy area?) The increased transmission frequency is not really applicable to most sailing boats (and frankly quite few motorboats as you need to exceed 14 knots).
Anyway, does anyone have any input on this? It feels a little like buying a dying technology when I need to replace mine now. It’s not really such a big price-bump, it is more the limited selection (Icom does not make a Class B SOTDMA transceiver). Em-Trak seems one of the few reasonable choices. Any knowledge or experience would be highly appreciated!
Kindly, Arne 🙂
Hi Arne,
Yes, as I understand it (have not spent any time on it) several manufactures are now producing AIS units to this new 5 watt class B+ standard. I guess if all else was equal I might spring for the extra money for one, but I don’t think it’s a big enough benefit to put over other features that I might want.
For others who are interested, here’s a good link: https://digitalyacht.net/2018/11/26/class-b-sotdma/
Hi John,
Thanks for sharing your recommendations. I am planning on upgrading the antiquated systems on my 36 foot sailboat possibly for another round trip from CA to HI. My upgrades will include a new radar and addition of an AIS transponder, and this article is helpful.
My current radar, Raytheon SL70, no longer works and never was as useful as I had hoped when I installed it long ago. But it did display a GPS goto waypoint and the AIS targets received by the Standard-Horizon 2150 VHF, both broadcast on NMEA0183, and it displayed ships and squalls. I am planning on replacing the radar with the Furuno 1815 or 1835.
Regarding AIS, the ICOM MA-500TR is very appealing – except that it does not appear to support ‘message 27’ which satellites pickup and relay so that AIS position is reported even far off shore. How important do you think having an AIS that broadcasts ‘message 27’ is?
https://www.navcen.uscg.gov/?pageName=AISMessage27
Apologies if this is covered elsewhere in your online materials; i searched without finding it.
Steve
Hi Steve,
I really don’t know and have not given it any thought, given that this is this is the first time I have heard of message 27! I guess my initial reaction is that it doesn’t matter much and is probably of interest primarily for security outfits trying to track bad people—interesting that this is on the homeland security site.
That said, if it turns out that SAR assets are using it, I could change my mind.
