At the end of my recent single-handed mini-cruise in a borrowed Hinckley 41 named Sable, I was working my way down a long channel in thick fog when a sailboat appeared directly in front of me and then turned to port.
Luckily I had been tracking them on radar and was ready for eventualities by standing at the helm and slowing right down to just maintain steerage way with the bow pointed to the starboard side of the channel. But if I had still been going ahead at even four knots I would have almost certainly tee-boned them. As it was, when I saw they were turning to port, I reversed hard to increase the clearance.
The crew of said boat was inside a full buttoned-up cockpit enclosure—probably why they did not hear my two-minute horn blasts—and steaming fit to beat the band in thick fog in a channel.
Why they did not see Sable on radar we will never know; maybe they confused her with a channel marker buoy.
Be that as it may, there are some important lessons in this incident:
A boat doing the same sort of thing nearly nailed Colin and Louise on Pèlerin a few years back. Come on people, navigating in fog is not a video game. We all need to read, and regularly reread, the COLREGS and follow them, as well as keep a good lookout. And that last includes opening up cockpit enclosures in fog so we can see and hear properly.
Don’t get me wrong, I’m not saying I have never made a mistake in fog, I have, but this kind of close call is both egregious and unnecessary.
Comments
A reminder that we have already done fog navigation in five chapters, see Further Reading below, so it’s not a good use of anyone’s time to redo all of that in the comments to this article, which I wrote to make a specific point (outside the paywall) about the dangers of turning to port and the importance of slowing down.
Of course, if you have a useful comment to add to the two points raised in this article, we are all ears. The same applies to comments relevant to the five articles linked to below.
Further Reading
- When turning to port ended very badly
- Four-part series on navigating in fog
- 8 Radar Use Tips
Also do not steer directly to navigational buoys in heavy fog, lest you find another boat arriving at the same place at the same time.
This is particularly true for buoys marking channel entrances leading from an area of open water.
Rather steer a comfortable distance to the side of the buoy and be highly alert as you approach it. I was almost run down by a west bound lobster boat off Outer Green Island in Casco Bay, and would have been if I had been steering directly towards the buoy.
Hi Lawrence,
I agree, in fact that is one of our core tips in the linked fog chapters. That said, we were in a buoyed channel when this happened so being reasonable close to buoys was unavoidable. That does bring up a point though. I was readily able to identify the oncoming boat because I had pre-identified the buoys so the minute I saw three targets where there should only be two, I knew there was a boat heading toward me. All part of keeping situation awareness.
Find if you have large screens (12” or better) the split screen setting to be helpful. Radar and AIS on one side with chart on the other. There’s no difficulties sorting out what’s what. Also find not using the AP wise. Don’t depend on your remote nor the ten degree button. Stand at the helm hand steer and be next to the engine controls. Think the AP produces many of the close quarters or limited visibility collisions. If your draft permits it run just outside the navigational markers. Colregs doesn’t stipulate you must run a channel except in a few instances. That way you stay out of the way of most commercial traffic and the majority of recreational operators who have never read the colregs. Finally as a mom and pop if the engine is on one of us goes forward or at least out of the cockpit. You hear much better.
Hi Lee,
Good points, but deviated from this channel would have meant walking. Also I was single handed, so hand steering, except at the last moment is not a good idea, too distracting.
Radio contact on 16?….if on colission course according to radar/AIS.
Hi Marek,
Good idea, but in this case, being single handed, I put my focus into other areas: tracking, slowing down, moving further to starboard, etc. Also they were not transmitting AIS, so calling by location would have been a further distraction. Tasks have to be carefully prioritized when single handed. Did I do that perfectly? Probably not, but then again we did not have a collision.
While not applicable in this situation, I do believe when using radar in restricted visibility and a vessel is on your starboard quarter, that would indeed be a turn to port. (Forgive me for being a bit pedantic…)
Hi Jamie,
Hum, I think it depends. Assuming that the vessel behind us is overtaking that makes us stand on vessel. So probably better not to alter at all, at least until required by the do-what-ever-it-takes rule 17(b) or we have agreed it via VHF.
Further if in a channel altering to port would push us out of our side of the channel 9(a). Now if another boat approaches from forward we are between between the two of them with few options.
That said, you are right in the situation covered under 17 (d ii)
Also an intersting read here: https://gcaptain.com/colregs-give-way-stand-part-two/
Hi Ernest,
Good article that I think applies to all of us. One criticism, he does not mention the option of going hard astern, which is what I did in the above situation, often the best option.
That said I particularly like this sentence:
Hi John, Ernest,
I believe the author is considering an ocean going ship as “stand-on” vessel – underway in a channel, with a small power boat crossing the bows (give way vessel). The ship going to full astern (especially if she is fully laden) is unlikely to reduce the collision risk in time, and could swing the stern to port (if RHS) and the bow to starboard exacerbating the situation.
Give way rights and sound signals change dramatically, once vessels are in sight of each other. At close quarters there is little time for VHF communication which can all too easily become “scanty” information. Sound signals are unambiguous, especially 5 or more short ones! I believe that was to be the subject of a part three article, but I couldn’t find it in my brief scan.
br. Rob
Hi Rob,
Good point on the dangers of going astern. That said, do note that the author said “inshore waters” not a channel. And also I wrote “option of going hard astern”. Not that it was the right course of action in every case.
To me the take away from the article is that if we recreational mariners cross the bow of a ship, particularly from port to starboard we deserve what the get!
As to calling on VHF, I think in cases where the other vessel is transmitting AIS it’s become a lot better option than it once was because when we know the vessel name it takes much less time and attention away from other tasks and the called vessel will recognize it’s for them much more quickly that the old location based calling method.
Hi John, this may be a translation issue. The article refers to “inland waters” and as a Kiwi and ex navigator on ships, I took this to infer a channel. In a North American context this could of course be on an inland sea/lake. No argumentation from me about your conclusions though. – spot on. Rob
Hi Rob,
Good point on the translation. You may easily be right. Anyway, the key point to me in that piece that scared the crap out of me is that ship navigators even need to be thinking about this!
Hi John,
Unfortunately the point you make is too true.
I was wondering whether you have a rule or set of rules for when you pro-actively change heading based on a non-visual radar only target and when you wait for visual contact? I personally do not have a rule and it is something I struggle to convey when setting up standing orders.
I have a hypothesis that modern chartplotters allow many more people to be out in the fog and also give those people the ability to travel at unsafe speeds. While I like my chartplotter it certainly feels more crowded out there in the fog than 20 years ago.
Eric
Hi Eric,
That’s a good point about standing orders. When in clear waters we operate as ships do and try keep a minimum CPA of 1 mile when burdened and call any vessel on VHF that seems likely to breach that boundary when stand on.
But in confined waters that’s obviously not a practical rule. In this case we still try to take avoiding action early and based on radar, well before we get a visual. In the case above I had very little time (less than 5 minutes) from when the target first appeared out of the land clutter to visual and so it was impractical to accurately access their track and speed. Given that uncertainty I stuck to the letter of the COLREGS by slowing down and moving well to starboard in the channel, as well as reading myself for evasive action.
Thinking back on it, there was a small area of deeper water outside the channel to starboard so it might have been even better to move into it. When available this is our usual course of action in confined waters. That said, being single handed in thick fog so doing could have resulted in me getting disoriented and grounding, so a risk trade off.
Hi John,
Thanks for the reply. We shoot for the same CPA offshore but also try not to pass that close in front of a big target if possible if we are in a crossing situation. My observation on confined waters is that most boats seem to use radar as early warning only and take action once they have visual but there are some exceptions. I strive to take action earlier but it is not always possible such as the scenario you mention where you don’t have a lot of maneuvering options and you have only recently picked up the target.
Being one of the slower vessels out there, I find it can be a real balancing act in higher traffic areas. If you take early action, you are forever steering around boats much faster and maneuverable than you and greatly increasing your exposure time. By the time you get a proper plot on that boat doing 15 knots in the fog (unsafe in itself), the course deviation required is enormous to have any real difference if you are only doing 5 knots. One of the key learnings for me was to figure out what a lobster boat looks like on radar, steering around them takes very different tactics than someone running a course and speed.
Eric
Hi Eric,
Yes, good points, particularly about fast movers and lobster boats. I guess, in the final analysis, once we are in confined waters it’s very hard to come up with one set of actions that always work and so it comes down to judgement and experience. This, in turn, makes the problem of inexperienced skippers enabled by plotters, that you mentioned earlier, even worse. I guess all we can do is keep pounding away on the importance of reading, and regularly rereading, the COLREGS. For example, if the boat that nearly got me had simply turned to starboard the encounter would have been way less scary.
But Not Always to Port..
“When in doubt, … turn to starboard (COLREGS Rule 14-a and Rule 19-d-i), … to avoid a collision. And, when in fog, particularly in confined waters, slow the hell down or, if any doubt, take all way off (COLREGS Rule 8-e and Rule 19-e)”
Incident May 2016. In fog. Visibility 50-75 Yards. Boat Speed 3 knots. Radar, AIS, Fog Horn, etc all in use. At helm open cockpit monitoring Starboard side (shore side) while I and a buddy boat (he to port and monitoring port side) proceed up Puget Sound separation 25 yards and a bit astern. Suddenly 4 headlights appear coming at my Starboard beam, closing at a high rate of speed.
First thought was to turn to starboard, but that would assure collision head on taking out mast. Hard turn to port, advance full power, begin to see separation, hit air horn – 5 blasts – repeat. Boat looks to be just missing stern. 3 sec from collision boat veers towards me 1 sec to collision boat veers away. Strikes my Starboard stern glancing blow. Buddy boats says my boat bounced across water 10 feet.
Point is. Be alert. Access the situation and remember to take action to Avoid the Collision.
Hi John,
Yes, that’s covered in Rule 17:
That said, this rule does not really apply, at least in theory, assuming that the boat coming from starboard was not more than 22.5 degrees abaft the beam, because you were the burdened vessel and so you should have turned to starboard (a full 180 if necessary) to pass behind them well before they got that close.
That said, I know how difficult this can be with fast movers and clearly boat that hit you was preceding at an unsafe speed.
A security call to the other vessel (if there is time) can help. The value of that was proved to me on a crossing of the English Channel under sail a few years ago, when we were on the blower to ships and fishing boats all night. I was surprised at just how accommodating the big ships were, in most cases changing course for us.
There is a standard for “early and substantial action” avoidance turns under radar, I believe it originated in the Journal of the Institute of Navigation. I’m unable to share my copy of it, but it looks something like this: http://www.splashmaritime.com.au/Marops/data/text/Radartex/Radarplottex_files/image024.jpg
Chuck
Hi Chuck,
That’s a great graphic, thanks for posting it.
The Andre Doria turned to port in fog and crossed the Stockholm’s bow.
