20 degrees is about right for modern, beamy boats, I’ve found. Once past that the underwater shape starts to tell and not in a good way.
Reef early, reef often!
Good point, although the J/109 is not that beamy, and neither is the M&R 56, at least by modern standards, so I think a lot of being able to sail well at low heal angles is about keel efficiency and keeping drag low.
That sounds right, but I don’t know for sure. You will also want to make sure you can read that out on whatever MFD you have.
Pete Running Bear
September 2, 2023 7:01 am
Agree that heel angle readout is great, as is rudder angle. Your compass should have trim too which is interesting both for long term and short term fore/aft weight distribution. Obviously the boot stripe will help with the former.
Michael Fournier
September 2, 2023 12:31 pm
Great article. Key is knowing your boat. Learned very early back at summer camp sailing lasers as a kid it may seem faster sailing with the rails in the water but the leeway increases and your added rudder to over come weather helm slows your actual over ground speed. Same can apply to those rule bending IOR boats with big over hangs designed to heel early will sail faster as the water line increases as they heel but the optimal angle range is narrow as weather helm will increase and then leeway and drag starts to slow you down again. (Not to mention risk of a broach)
Jean-Louis Alixant
September 3, 2023 12:00 pm
It is indeed about “knowing your boat”, and that can take time. One way to cut down the time and effort is to use the output of a VPP: that will provide the theoretical optimal Heel angle for the full range of TWS and TWA pairs. It usually provides a very good starting point.
If you don’t have the data for your own boat, lookup the information for similar ones, they will provide useful trends and indications, which you can then adjust and refine.
If you know your boat well, VPP outputs can still provide a healthy challenge for established habits and may point to performance opportunities.
I agree, knowing where success lies is really helps when learning how to sail a new-to-us boat well. I was fortunate that all that stuff came with out J/109, although it would have been fairly easy to find on the internet.
Philippe Candelier
September 3, 2023 3:46 pm
I discovered that those inclinometer have also a great psychological effect: once you can put a number on the heel angle, suddenly for most young crew (young to sailing a monohull) life is good. No more anxiety about 15-20 degrees heeling.
Alastair Currie
September 8, 2023 11:07 am
I bought the Sun Coorporation’s Lev-o-gauge SR model and stuck it on the bulkhead facing aft to my helm position. It works great, is damped very well and nice and clear. Downside it is a bit industrial looking. For my Rival 41C at 41′ LOA, 12.2′ beam and 5.9′ draught, 10 tonnes, deep forefoot and encapsulated fin, I find around 30 degrees I have too much weather helm, digging in the side decks and just a lot of drag. I tend to sail upwind around 25 degrees max and get all the drive I need.
It is a neat tool to use, which gives that reference number to what was gut feel angle anyway. I have been using it for about 3 years now.
I have always spelled it “heel”, and merriam-webster seems to agree with that spelling. is heal a common spelling in the northeast?
Hi James,
No it’s a common spelling among dyslexics, of which I’m one! I will change it, thanks.
Hi John
20 degrees is about right for modern, beamy boats, I’ve found. Once past that the underwater shape starts to tell and not in a good way.
Reef early, reef often!
Hi Colin,
Good point, although the J/109 is not that beamy, and neither is the M&R 56, at least by modern standards, so I think a lot of being able to sail well at low heal angles is about keel efficiency and keeping drag low.
I was thinking about buying one of these https://www.airmar.com/Catalog/Marine/GPS-Heading-Sensors/GH2183
It outputs pitch and roll to the network so I guess you could read the roll as heel angle?
Hi John,
That sounds right, but I don’t know for sure. You will also want to make sure you can read that out on whatever MFD you have.
Agree that heel angle readout is great, as is rudder angle. Your compass should have trim too which is interesting both for long term and short term fore/aft weight distribution. Obviously the boot stripe will help with the former.
Great article. Key is knowing your boat. Learned very early back at summer camp sailing lasers as a kid it may seem faster sailing with the rails in the water but the leeway increases and your added rudder to over come weather helm slows your actual over ground speed. Same can apply to those rule bending IOR boats with big over hangs designed to heel early will sail faster as the water line increases as they heel but the optimal angle range is narrow as weather helm will increase and then leeway and drag starts to slow you down again. (Not to mention risk of a broach)
It is indeed about “knowing your boat”, and that can take time. One way to cut down the time and effort is to use the output of a VPP: that will provide the theoretical optimal Heel angle for the full range of TWS and TWA pairs. It usually provides a very good starting point.
If you don’t have the data for your own boat, lookup the information for similar ones, they will provide useful trends and indications, which you can then adjust and refine.
If you know your boat well, VPP outputs can still provide a healthy challenge for established habits and may point to performance opportunities.
Hi Jean-Louis,
I agree, knowing where success lies is really helps when learning how to sail a new-to-us boat well. I was fortunate that all that stuff came with out J/109, although it would have been fairly easy to find on the internet.
I discovered that those inclinometer have also a great psychological effect: once you can put a number on the heel angle, suddenly for most young crew (young to sailing a monohull) life is good. No more anxiety about 15-20 degrees heeling.
I bought the Sun Coorporation’s Lev-o-gauge SR model and stuck it on the bulkhead facing aft to my helm position. It works great, is damped very well and nice and clear. Downside it is a bit industrial looking. For my Rival 41C at 41′ LOA, 12.2′ beam and 5.9′ draught, 10 tonnes, deep forefoot and encapsulated fin, I find around 30 degrees I have too much weather helm, digging in the side decks and just a lot of drag. I tend to sail upwind around 25 degrees max and get all the drive I need.
It is a neat tool to use, which gives that reference number to what was gut feel angle anyway. I have been using it for about 3 years now.
https://levogage.com/products/product_00f548e4-138f-2a38-b46e-d5da7c324ca6
