For about half the cost of the Watt and Sea you can buy a Duo- Gen from Eclectic Energy in the UK. It produces 6-8 amps at 5-7 knots in water mode and is a useful wind generator at anchor
Hi Ted,
I sailed across the Atlantic on a Saga 43 fitted with a DuoGen – it worked so poorly that the owner replaced it with a W&S for the return voyage. A case of the classic trying to do two things well and ended up doing both things poorly. If you’ve had luck with yours that’s great. I’m only speaking from my own experience, and the DuoGen can’t hold a candle to the W&S, especially on output.
There are other options too. Ampair makes a towable generator for a few hundred bucks, and I may be missing some others. Yves Gelinas made his own homemade towable generator in the early 1980s when he sailed around the world solo on his engineless Alberg 30 ‘Jean-du-Sud.’
-Andy
Hi Andy
We have crossed the Pacific from Canada and made several trips from New Zealand to the Islands and Duogen has been very good. Less output than the WS but still sufficient to power everything in conjunction with our solar panels.
Hi Ted, happy to hear that, good on you!
Andy
Thanks for the honest review of the Wattsson,s real life capabilities and shortcomings. Many reviews fail to look at the full picture for a host of reasons.
Thanks Dave, appreciate the compliments!
Hi Andy
a very thorough and fair review of the Watt and Sea. Having used a couple (on a Boreal 47 and a 55) I’d add a few comments.
The standard bracket is the weak spot. The custom bracket Boreal fabricate is massive and works well, although the vertical pin needs to be lubricated to keep it quiet and easy to remove. If W & S have now come up with a custom bracket, then that has to be a good thing.
I’ve experienced that rumbling and vibration from the unit and put it down to bearings (worryingly), and I’ve heard complaints of the same from other users – there has to be some way to identify what the problem is and for W & S to cure it, as it is (in my view) too frequent an issue for comfort.
As an aside, anyone considering one for these units alongside a servo pendulum vane gear where the auxiliary rudder swings from side to side will have their work cut out to come up with a solution to stop the rudder and the W & S prop possibly meeting with disastrous results! They move around far more than I had expected. It is just possible to set up the Windpilot Pacific on a Boreal and the W & S to work at the same time – but it’s close. The vane gear can be angled slightly to make the necessary clearance without compromising the efficiency of the gear, but if a fix has to be made by altering the bracket of the W & S, then as you’ve identified, the work will need to be done to a very high standard indeed.
And I totally agree with your summation – a great thing to have on a long distance voyaging boat, but not for coastal cruising.
Best wishes
Colin
Hi Colin,
There’s two kinds of ‘rumbling’ I’ve experienced – the first, and less concerning, is when the batteries are fully topped up and the W&S is essentially ‘freewheeling.’ It’s an ominous noise, but according to everyone I’ve spoken to, unavoidable and not bad for the unit. So when we get to fully topped batteries, we either take up the W&S, or more likely, just run the watermaker a bunch to use the electricity! Problem solved.
The second was what I describe on our last day offshore en route to Horta. It was a terrible vibration, and the batteries were NOT fully topped up, so it was different. It was still putting out amps, but obviously something was wrong. I’m sending that one back to W&S, it’s still under warranty, so I’ll report back if I get an answer from them what it was all about.
Andy
I bought a tow generator from Hamilton Ferris while in New Zealand in 1994. I sailed
SEA BEAR ( 39 ft steel cutter) singlehanded to Rio de Janiro, via Drake’s Passage, on my way to Maine. I only Started the engine once a week to be sure it would still run. The tow generator provided all the power I needed ( lights, radar, radio, no fridge) and I only towed it a few hours a day. Still have it and use it on passages. Simple and pretty inexpensive.
That’s great Peter! I’m envious of your small and simple boat – I miss our Arcturus a lot, especially when dealing with this expensive stuff! But alas, I need a bigger boat to run the business, and need a watermaker to keep the crew going, and subsequently need a way to make power! Good on you for keeping it simple!
Hi
We bought the 300W short leg version for our 31ft boat. The size of the propeller and unit is dependent on the boat one has. The 600W unit would have been nonsense for our boat since we never reach enough speed to use the upper 300W. The choice of propeller size and unit wattage should be made based on average passage speed. There are output curves on the W&S homepage.
We had to mount our unit eccentric on the starboard side to keep it away from the wind vane. Initially I regretted buying the short leg unit because the propeller sometimes breaks the surface on starboard tack. This turned out to be an advantage when we came into sea areas with much seaweed because the propeller rids itself of seaweed when breaking the surface (most of the time).
For anybody buying two units Iâd recommend to buy two units with short legs and mount them on both sides of the transom. Mount them removable with a plug. If any unit fails the good one can be moved to the lee side. This would be the perfect solution for me that also leaves space for the windvane. The stress on the mounting will be considerably less for the short leg unit too. (I find the mounting on the picture still does not look very solid.)
The W&S-regulator doubles as a MPPT solar regulator. I bought 300W of portable solar panels that I use at anchor (en.sunware.solar/produkte/module_textil_tx). This is enough for our energy needs including refrigeration and watermaking. Portable panels are superior to fixed mounted ones since they can be moved around on deck and out of the shadows. This is even more important in the arctic where solar panels need to be angled towards the sun to be effective. Unlike almost everybody else we do not have a windgenerator and never missed it.
W&S have a good service and they are one of few French companies that deliver a comprehensible manual in languages other than French (most others seem to use google translate or worse).
In 14 month of fulltime cruising we never started the engine for charging and on our first Atlantic crossing we did not start the engine at all.
We also experienced the rumbling sound that Colin mentions. A technician from W&S replaced our generator unit witch solved the problem – for about 5 days. Thereafter we just left it. It does not impair energy production. The technician said he wanted our old unit to find out what causes the sound.
Never ever angle the pendulum rudder on your Windpilot!!! Peter from Windpilot told me this is a big mistake. Doing so produces to much stress on the mechanics and will damage the system (I did it and it broke my windvane). Windpilot produces different extensions for the mounting. Buy one that is long enough to keep the pendulum rudder vertical and away form the Hydrogenerator.
Hi Enno,
Good point about the 300W unit for slower boats that would never get the added 300W out of it anyway. I’m still not sure it’s worth the expense, but if you’ve had luck with it, that’s excellent. I have no comment on the wind pilot, as I have no experience with that particular gear.
I also have similar good things to say about W&S and their manuals and service, for the most part.
I have purchased a 300 watt unit for my boat and have been thinking about the mounting requirements. My understanding of the situation is that the center of the propeller should be a minimum of 12″ below the waterline. More precisely, wouldn’t that be the dynamic waterline? The waterline when our boat is sailing at 5 knots or greater?
If that is the case, it makes little difference how high your transom is from the water at the dock because when sailing it will be very near the water.
Hi Caleb,
Yes, get the unit as low in the water as you can. You make a good point about the sailing waterline, but there’s a few caveats. 1). We have ours mounted centerline – when we’re going hard to windward, and heeling 20-30Âș, it’s barely in the water. Yes, the waterline down on the low side stretches aft, but centerline it’s still high, and remember, the W&S will be angled AWAY, the same amount the boat is heeled. 2). In light airs going downwind, and with any swell, the prop often comes out of the water completely as the stern rises under a wave. No harm, but you’re losing some precious amps! 3). Finally, we had ours mounted such that it sits the requisite 12″ underwater even at the dock – that’ll only help when the boat digs in when she starts sailing.
Andy
Andy, I have puzzled over these issues for some time. Our solution (to date) was to go for a larger bank: six L-16 6 VDC in series-parallel for a total of 1575 Ah capacity, of which I consider one-third conservatively useable. And it’s right under the mast, which is nice, beneath rebuilt saloon steps.
We have four 135 W solar panels, a 300 W wind generator and will sport a pair of 90-110 A alternators. The idea, like yours, is to make amps while we can and “go quiet” electrically where we can’t. If I’m motoring anyway, I’ll take the output happily, but, like you and Mia, that’s not the goal, nor would we have a diesel genset to that end. Our windvane installation, as has been pointed out, likely precludes this generator, but it’s an excellent review that made me at least think about it for a minute!
Good on your Marc! Probably not worth the expense or maintenance in your case, you sound like you’ve already figured it out.
Hi Marc
Can you point me to a web address for your batteries. I assume from the description of your house bank that the individual 6 volt batteries are 525 Ah each. I’d be interested to follow up on size and weight.
Thanks in advance,
Bill Attwood
I can give you the blog post I made on the topic, which features the spec sheets:
https://alchemy2009.blogspot.ca/2016/05/getting-lead-in-part-1.html
They are sold by Crown primarily for electric forklifts and sweepers, but also are popular with the off-grid crowd. They aren’t easy to source; not rare, but you have to be specific as the 430 Ah ones are far more common. They weigh about 125 pounds each: I shifted them as detailed here: https://alchemy2009.blogspot.ca/2016/07/getting-lead-in-part-2.html
I was in contact with an off-grid homesteader named “Handy Bob”, who was kind enough to give me a lot of good advice on the care and feeding of lead-acid batteries of this capacity: https://handybobsolar.wordpress.com/
Certainly, my successful baptism into off-the-dock electrics has been greatly enhanced by the experience of off-grid renewable tech and installation/monitoring techniques. For sailors going this route, those sorts of resources are invaluable.
Hi Marc
Many thanks, and I look forward to following up your tip about off-grid homesteaders.
Yours aye
Bill
You didn’t mention any performance penalty. There must be some drag associated with that unit.
Hi Greg,
Good point. I’ve never bothered to test it. I don’t notice any drop in performance at all, which is in line with what W&S promotes, and what others have said. The racing version has hydraulically adjustable pitch on the propellor blades to optimize output v. drag, but not the cruising version. And anyway, it hardly matters even if it’s costing us half a knot (which I KNOW it’s not). The power it produces is well worth whatever very minor penalty there is in boatspeed.
We gained half a know with our Gori folder on our sloop and our feathering Variprop on our cutter. I would give some or all of that back to never have a generator or to “need” to run the engine for charging over propulsion. But that’s me. Everything’s a trade-off and most people can jog faster than the average cruiser in average conditions can sail…over a mile course, at least!
Interesting article appeared in my morning email. Practical Sailor reviews towed generators: https://www.practical-sailor.com/blog/Towed-Water-Generators-Are-They-Worth-It-11090-1.html?ET=practicalsailor:e35590:1991072a:&st=email&s=p_Waypoints082417
I agree on most of Andys article. However the crucial point is for sure the bracket – I also figured out that the hinges are too weak for the loads which are act on the watt and sea – especially when sailing upwind in big waves. I also replaced my bracket in Cape Town by a carbon fiber one and replaced the hinges with stainless ones. Done so far about 20 K miles offshore with this power plant and I am completely satisfied so far. I using it on a Luffe 45 you can find some pictures under http://www.lifgun.com
I have just realized that there is a new version called pod 600 that is to be installed below the hull, aft of the keel. As I have a large opening transom on my Beneteau Oceanis 48 I am thinking about the pros and cons of such a solution.
I like the âout of the wayâ feature of such a setup, it has a shorter shaft and thus less force on it, is always under water, less in danger of debris behind the keel. But it needs additional holes in the hull, is not easily reachable for maintainance, always on or blocked (with increased drag?) by an off-switch/relay.
Any experience or suggestions on this type of solution?
Thanks and best regards,
Klaus
BTW, hereâs the link to the Watt and Sea website showing the pod 600:
https://www.wattandsea.com/en/products/cruising-hydrogenerators/pod-600
Hi Klaus,
I don’t have any experience with these generators so this is speculation, but speculation based on a lot of offshore miles.
That said, given the reliability problems with these generators I would not consider this option because of the difficulty of service, which you, quite rightly, highlight.
As to alternatives, I think I would consider a small generator instead, perhaps something like this: http://fischerpanda.com/fischer-panda-dc-agtpm5000/
An advantage being that it could also be used at anchor.
Hi John,
thank you for your feedback! I tend to agree that it is potentially a not so reliable solution.
On the other hand I am quite satisfied with my decision NOT not to have a combustion engine generator on board. Another piece that burns fossil fuel, is noisy and needs engine service regularly.
Nearly 600 Wp of solar at the davits work well in tandem with 1,100 Ah of service batteries, so far for all situations except when running multi-day on auto-pilot + watermaker like we did for the Atlantic crossing. This type of energy need is what I am looking to solve with a Watt & Sea hydro generator.
So I will keep investigating how to best fix the 600 watt long shaft version to my boats transom.
Hi Klaus,
I have no personal experience with the Watt&Sea but I did want to share a general thought on energy production. One of the things that happened with early off-grid solar systems is that people focused too much on the worst case situation and ended up with huge arrays that were far larger ($ and carbon footprint) than needed for the vast majority of the time. Many of these systems were replacing generators and and it turns out to be not a bad idea to size for the vast majority of the time and either lessen loads occasionally or turn that generator on.
If you are doing what Andy does where he makes a living by sailing tons of miles, then I think a combination of solar, wind and hydro that covers nearly all needs is an excellent idea. However, if you are someone who mostly coastal cruises and every 5 years does an offshore passage over 4 days where your solar doesn’t keep up, I would argue you should at least consider using the main engine occasionally. While the engines’ efficiency is very low at this sort of task, your overall system efficiency is likely higher over the course of owning the boat thanks to not carrying the other generation sources around all the time when not needed. You can also do things to boost the efficiency such as trying to match charging time to slow sailing periods when a little speed boost wouldn’t be bad and also trying to only run the engine when the batteries are low so you can get full alternator output and let the solar top it up (assuming lead acid batteries). The drawbacks of going this way is that you do burn a bit of extra fuel which you hopefully have the capacity for and you lose some redundancy.
I have no idea what your particular usage profile is but just wanted to throw this into the conversation as people can become fixated on covering 100% of needs without using the main engine as opposed to using it to charge maybe 5 times a year. With our 140W tilting panel and MPPT controller, we almost never have to start the engine just for the purpose of charging and when we do, I don’t sweat the maybe 3 hours a year we do it.
Eric
Hi Klause and Eric,
Funny, I was just in the car thinking about your situation and was ready to comment as soon as I got back to the office with exactly the same recommendation as Eric made: run the main engine and don’t worry about it.
That said, Eric has done a better job of explaining the reasoning than I would have, although I do have some thoughts on the same vein here:
https://www.morganscloud.com/2016/07/19/battery-replacement-resisting-the-seduction-of-perfection/
One added suggestion: You may want to make sure you have a good alternator and a regulator that’s programmed well. See these posts:
https://www.morganscloud.com/2013/11/06/10-tips-to-buy-and-install-a-liveaboards-alternator/
https://www.morganscloud.com/2020/07/04/stupid-alternator-regulators-get-smarter-finally/
There two upgrades will cost a fraction of what a Watt and Sea will and will, for most usage profiles, be far more useful.
Hi Eric, John,
great thoughts to work with, thanks a lot!
On my sailing profile, I plan to cross the Atlantic two more times before I hope to start a long term voyage that might include crossing the South Pacific, all during the next few years. Becoming a live aboard is what I am working on. đ
So far I have used the main engine to top up the batteries when solar has not been sufficient or loads have been high like with autopilot and watermaker loads over sustained periods of time. For that reason I have installed a Sterling AB1280 regulator that keeps the amps coming from the alternator and offers a 3-phase charging cycle on the batteries end of things. (https://sterling-power.com/collections/alternator-to-battery-chargers/products/alternator-to-battery-chargers-up-to-130a). I know some people think that this product is not a good idea for a few reasons. On the other hand I know of a trusted 30-year-in-business service technician that has personally installed and serviced dozens (or even hundreds) of those setups without experiencing or knowing of a single failure/issue.
Burning fuel for charging purposes adds up on the fuel consumption side quite fast and leaves less reserve capacity fuel for motoring if weather conditions ask for. My next leg will be from Caribbean via Azores back to Europe where having full fuel tanks might increase options navigating the weather situations. In my opinion this increases safety. Would you agree?
I looked into the costs of installing a larger alternator with programmable regulator and it is not far off the cost of installing a Watt & Sea hydro gen (total about EUR 4,000). The currently installed alternator on my Yanmar 75hp engine has only about 1000 hours of usage, most of it in low load situations and without the Sterling regulator setup. Should be good for another 1000+ hours without touching the system, I would guess.
All that said led me to the conclusion that going with a hydro gen installation seems to be a great solution as it increases safety, one by adding redundancy and two by increasing the range I can go by fuel if weather conditions ask for. Increased self sufficiency and ability to drive a large fridge/freezer are additional soft/convenience factors.
Andy, how are you âlashingâ the unit in the down position? I share your concerns and dislike for the rather small, point-loading pin, but havenât arrived at an effective alternative to keep the unit firmly seated in the v-notch over time without placing the pin.
Hi Jonathan,
I’ll try to dig up a photo, as I think it’s impossible to describe here. But in short, it worked great – once lashed down when the boat is stopped, it doesn’t come undone at all. I’m going to make it simpler next season too, this was sort of temporary to see if it worked or not, but it most definitely does.
Andy
Hi Andy,
If you send me the photo I will add it to the post.
I installed the larger Watt and Sea unit in Vancouver before we left. On the way down the coast to San Diego I honestly thought it wasn’t working. We had it checked by a professional in San Diego and they assured me it was working fine. We changed the prop to the larger one that would be better at lower speeds. They showed me the chart where it says 5 knots and up for good charge. Below that little power. Sail faster they said. Down the coast to Puerto Vallarta we did get some power output now that I knew how to check it. Flashing lights under the unit in the rear compartment. Impossible to see but I could get a video of it. It was working. We left for the big passage to Tahiti. As usual 2 hours on the engine in the evening to get 95% + charge. I later discovered that and hour in the morning and an hour at 6.00pm did a better job of charging. In the year I passed over the Equator we had a low wind year. We had reckoned on 23 days to the Marqueses. It took us 27. No mater. We enjoyed the sail even though it was a bit slow. We mostly made 3 to 4 knots bursting up to 6 + during the Squalls which fortunately were not too often. Scary as they were!
I have an Island Packet 40 foot. The only sail we did manage 6 knots average was from Hawaii to Vancouver when we had frequent storms and relatively high winds. Very uncomfortable. We are a power hungry boat. Auto Pilot. Older fridge that doesn’t have the insulation that modern ones have. SSB radio that we operated for at least an hour every night, very power hungry to broadcast. Lights. Multiple computers and phones Many batteries to re-charge. etc.
Would I install the Watt and Sea again? Yes, probably as when it does work its great. It’s a love hate thing. It is vulnerable to damage in harbour and around other boats. You have to get it set down properly before heading out to sea. Trying to pull it down against the water flow when going forward is very hard. The French system of lowering it is poor. It really needs a bolt to hold it in place when fully down. Would two devices work better on the same boat. Not really. You need a faster boat.
S V Music.
Hi Bill,
Thanks for a great field report, always the best information. Really highlights the difference we so often see between claims and reality.
Sorry to be late to this party.
We had a Sail-Gen, Eclectic Energyâs hydro-only version of their DuoGen, on our last boat and we have a Watt&Sea 600 on our current boat. The Watt&Sea is considerably smaller, lighter, and less cumbersome than the Sail-Gen with the result that it is much easier to mount, lower and raise, store and move about on deck with. And its electrical performance is a bit better. (The DuoGen is a permanent fixture so not all of these points are relevant.)
The Watt&Seaâs gudgeons are bolted to pintle brackets which, in turn, are bolted to an aluminium plate. The plate drops into a slot welded on the vertical transom and is held in place with a couple of retaining bolts. The same welded slot also features in the sail locker which makes securing the device when stored very straight forward. All credit to Allures Yachting for a well thought through and well executed design.
We have done over 11,000 NM with the Watt&Sea actually in the water (with two stints of over 2,000 NM where the device was never lifted) and have had very few problems.
The first was the pointed end of the 5mm retaining pin that Watt&Sea provides getting bent while trying to remove it without the boat being almost at a stop. I now use a 6mm SeaSure big head drop nose pin where the drop nose part stops the pin from working its way out. It is concerning to read about the failure of the plastic cap (through which the retaining pin slots) on Andyâs first unit and Iâd be very interested to know more about his lash-down mechanism (comment of Nov 14, 2017).
The second was elongation of the holes in the gudgeons at around 5,000 NM. I had these bushed out and use Tef-Gel as a barrier and lubricant. They look good as new after 6,000 NM.
The third is that the Watt&Sea doesnât work when you are in a field of sargassum weed as we were for four days on our 2021 crossing from Lanzarote to Grenada! Which brings me to the Watt&Sea pod, the permanently hull-mounted version of the generator. In our experience it is essential that you can get to the generator to remove weed, either by lifting the generator clear of the water or using a gaff hook. With the pod, a fouled unit would be out of action until the end of the passage unless someone is willing to go under the boat to sort things out.
But the pod manual (section 5.2) does contain the solution to the rumbling that occurs when the batteries approach fully charged. When I asked Watt&Sea about the problem, they said to raise the generator, a somewhat impractical solution given the need to slow the boat to almost a complete stop (to both raise and lower it) and the difficulty of removing the retaining pin in big seas.
When I also pointed out that this solution wouldnât work with the pod, Watt&Sea came back with the correct solution which is to short together all three of the generatorâs phase wires (which has the effect of stopping generation), implemented using a 3-pole relay. For 12v systems, Watt&Sea supply a Finder 62.83.9.12.0000. Ours is enabled using a 2-pole switch, the second pole being used to activate a flashing red LED which serves to remind me to reenable the Watt&Sea when the sun goes down.
In a lithium battery system, the relay could be activated by the BMS to prevent overcharging of the batteries. Although in that situation, if you have a lead acid sub-system dedicated to the navigation lights and essential instruments, it would be an option to have the Watt&Sea power only that sub-system so avoiding the lithium overcharging problem.
On a any passage that involves being at sea over night, the Watt&sea gets deployed.
Allan
sv Stravaig
Hi Allan,
Thanks very much for the real world report filled with useful information. I’m sure others looking at water generation will find your experience invaluable.
The big take away for me is that we need a system that can be easily raised and lowered underway before water generation can be considered really user friendly. Any thought on alternatives to fill that need? I see plenty of photos of W$S units kicked up, but don’t know anything more about the issues with that.
Hi John
The reason you see these units kicked up is that the leg needs to be lifted before going astern otherwise bad things can happen to the leg and mountings. After entering a marina or harbour, not only do we lift the leg (using a 4:1 attached to the arch), we also move the entire unit to the foredeck where it is tied to the granny bars temporarily, out of harmâs away; it is easy to do this on flat water.
Iâve just visited the W&S site (my these guys have been busy – several new products including a wind generator) and the design of all of the retractable models involves a swinging leg akin to the rudder on a typical dinghy where, in my experience, getting the thing down and keeping it down was always a challenge. With the Watt&Sea, if you use a retaining pin to keep the unit down (as we do), you need to get quite close to the water to insert it and remove it which is why Iâm curious to know more about Andyâs lashing technique.
One possible solution would be to swap the swinging leg for a leg that goes up and down based on the screw jack based mechanism used to lift and drop the keel on trailerable sports boats. But coming up with a design that works with all transom shapes is probably why W&S hasnât gone there. Perhaps Iâll drop them a line to see if this is in the pipeline.
Allan
Hi Allan,
Yes, I get why we need the unit to kick up, it’s the how that I have been thinking about. It seems to me that really good mounting with reliable retrieval that stays down when you want it to is still something standing in the way, particularly since I totally agree with you that the pods are not a good idea.
I like your idea of a screw jack. I also seem to remember that Boreal cracked the problem, but I may be wrong about that. Will check with Colin the next time we chat.
The W&S is top of mind for me at the moment since I have been thinking a lot about the electrical system for the A40 and this seems a good option for many owners rather than festooning the boat with an unseamanlike huge solar array.
On passage, the W&S complements solar providing three benefits: meeting the increased load (instruments and autopilot), backup when the sun doesnât shine, keeping the batteries topped up overnight so minimising DoD and possibly extending their life. The first point means you only need to size the solar for being at anchor.
On a related point, not all solar panels are created equal. From day one, the best Iâve seen from the arch-mounted rigid solar panels fitted by the boatyard during build is 57% of their rated output (and after four years, thereâs no significant change in that figure so no obvious deterioration). With the boatyard fitted solar not meeting our needs I added a couple of semi-flexible SunPower Maxeon panels on the bimini (not great I know). Much to my surprise, they do deliver to specification and on occasions exceed it (and I know of others with the same experience). For a given surface area, they deliver almost twice what the boatyard fitted panels deliver. So the plan now is to return to a more seamanlike config by ditching the semi-flexibles and replacing the rigid panels with high efficiency ones while writing off the costs to experience and learning.
Allan
Hi Allan,
Yes, to me the main reason for a W&S is to feed the autopilot. A40 owners who stick with a vane gear probably won’t need it.
That’s a good point on panel quality, although more of a difference than I was aware of. Have you compared the two on an area basis? I ask because I’m wondering if at least part of the difference could be Maxeon being more conservative in their output claims.
Oops, sorry, just reread your comment and and picked up that you have already covered that…”read more carefully, John”.
Good plan on getting rid of the bimini panels
